128 Datasheet
Intel
®
Celeron
®
Processor up to 1.10 GHz
Table 62. Input/Output Signals (Single Driver)
Name Active Level Clock Signal Group Qualified
BSEL[1:0] Low Asynch Power/Other Always
BP[3:2] Low BCLK AGTL+ I/O Always
BR0# Low BCLK AGTL+I/O Always
A[31:3]# Low BCLK AGTL+ I/O ADS#, ADS#+1
ADS# Low BCLK AGTL+ I/O Always
BPM[1:0]# Low BCLK AGTL+ I/O Always
D[63:0]# Low BCLK AGTL+ I/O DRDY#
DBSY# Low BCLK AGTL+ I/O Always
DRDY# Low BCLK AGTL+ I/O Always
LOCK# Low BCLK AGTL+ I/O Always
REQ[4:0]# Low BCLK AGTL+ I/O ADS#, ADS#+1
Table 63. Input/Output Signals (Multiple Driver)
Name Active Level Clock Signal Group Qualified
BNR# Low BCLK AGTL+ I/O Always
HIT# Low BCLK AGTL+ I/O Always
HITM# Low BCLK AGTL+ I/O Always
PICD[1:0] High PICCLK APIC I/O Always
