Intel Desktop Board D410PT Technical Product Specification
32
1.11.2.3 Instantly Available PC Technology
Instantly Available PC technology enables the board to enter the ACPI S3 (Suspend-to-
RAM) sleep-state. While in the S3 sleep-state, the computer will appear to be off (the
hard drive(s) and fan will power off, the front panel LED will blink). When signaled by
a wake-up device or event, the system quickly returns to its last known state. Table 9
on page 30 lists the devices and events that can wake the computer from the
S3 state.
The board supports the PC
I Bus Power Managem
ent Interface Specification. Add-in
boards that also support this specification can participate in power management and
can be used to wake the computer.
The use of Instantly Available PC technology requires operating system support and
PCI 2.3 compliant add-in cards and drivers.
1.11.2.4 Wake from USB
USB bus activity wakes the computer from an ACPI S1 or S3 state.
NOTE
Wake from USB requires the use of a USB peripheral that supports Wake from USB
and support in the operating system.
1.11.2.5 PME# Signal Wake-up Support
When the PME# signal on the PCI bus is asserted, the computer wakes from an ACPI
S1, S3, S4, or S5 state (with Wake on PME enabled in the BIOS).
1.11.2.6 Wake from PS/2 Devices
PS/2 keyboard activity wakes the computer from an ACPI S1, S3, S4, or S5 state.
However, when the computer is in an ACPI S4 or S5 state, the only PS/2 activity that
will wake the computer is the Alt + Print Screen or the Power Key available only on
some keyboards.
1.11.2.7 Wake from Serial Port
Serial Port activity wakes the computer from an ACPI S1 or S3 state.
