2.2.4.3 Power Supply Connectors
The board has the following power supply connectors:
• External Power Supply – the board can be powered through a 12-19 V DC
connector on the back panel. The back panel DC connector is compatible with a
5.5 mm/OD (outer diameter) and 2.5 mm/ID (inner diameter) plug, where the
inner contact is +19 (±10%) V DC and the shell is GND. The maximum current
rating is 10 A.

NOTE
External power voltage, 12-19 V DC, is dependent on the type of
power brick used.
• Internal Power Supply – the board can alternatively be powered via the
internal 12-24 V DC 1 x 2 power connector, where pin 1 is GND and pin 2 is
+19 (±10%) V DC.
Table 19. 12-24 V Internal Power Supply Connector
Pin Signal Name
1 Ground
2 +19 V (±10%)
For information about
Refer to
Power supply considerations Section 2.5.1, page 52
2.2.4.4 Front Panel Header (2.0 mm Pitch)
This section describes the functions of the front panel header. Table 20 lists the signal
names of the front panel header. Figure 11 is a connection diagram for the front panel
header.
Table 20. Front Panel Header (2.0 mm Pitch)
Pin
Signal Name
Description
Pin
Signal Name
Description
1 HDD_POWER_LED Pull-up resistor
(750 Ω) to +5V
2 POWER_LED_MAIN [Out] Front panel LED
(main color)
3 HDD_LED# [Out] Hard disk
activity LED
4 POWER_LED_ALT [Out] Front panel LED
(alt color)
5 GROUND Ground 6 POWER_SWITCH# [In] Power switch
7 RESET_SWITCH# [In] Reset switch 8 GROUND Ground
9 +5V_DC Power 10 Key No pin
