Technical Reference
53
2.5.2 Fan Header Current Capability
Table 23 lists the current capability of the fan headers.
Table 23. Fan Header Current Capability
Fan Header Maximum Available Current
Processor fan .25 A
2.6 Thermal Considerations
CAUTION
A chassis with a maximum internal ambient temperature of 50
o
C at the processor fan
inlet is a requirement.
CAUTION
Failure to ensure appropriate airflow may result in reduced performance of both the
processor and/or voltage regulator or, in some instances, damage to the board.
All responsibility for determining the adequacy of any thermal or system design
remains solely with the system integrator. Intel makes no warranties or
representations that merely following the instructions presented in this document will
result in a system with adequate thermal performance.
CAUTION
Ensure that the ambient temperature does not exceed the board’s maximum operating
temperature. Failure to do so could cause components to exceed their maximum case
temperature and malfunction. For information about the maximum operating
temperature, see the environmental specifications in Section 2.8.
CAUTION
Ensure that proper airflow is maintained in the processor voltage regulator circuit.
Failure to do so may result in shorter than expected product lifetime.
