Reference Thermal Solutions
R
Intel
®
E7500/E7505 Chipset MCH Thermal Design Guide 29
Figure 16. Retention Mechanism Component Keep-out Zones
850_Keepout_Zone
0.896
0.345
0.120
1.156
0.170
(0.165)
0.100
0.225
2x 0.060
(0.345)
See Detail A
0.070" Component
Keepout
0.100" Component
Keepout
0.165
0.100
0.200
0.173
0.345
0.083
2x 0.038
Plated Through Hole
Component Keepout
Detail A
2x 0.056
Trace Keepout
NOTES:
1. Dimensions are in inches.
2. Not to scale.

Intel E7500 Specifications

General

Processor Number	E7500
Number of Cores	2
Number of Threads	2
Base Frequency	2.93 GHz
Bus Speed	1066 MHz
TDP	65 W
Socket	LGA775
Core Architecture	Wolfdale
Manufacturing Process	45 nm
Instruction Set	64-bit
Virtualization Technology	Yes
Integrated Graphics	No
Cache	3 MB
