INVT GD20-0R7G-4-EU User Manual

Goodrive20-EU series VFD Peripheral options and parts
159
C.6.5 C2 filter
Model
Input filter
Output filter
GD20-0R4G-S2-EU
FLT-PS2010H-B
FLT-L04006L-B
GD20-0R7G-S2-EU
GD20-1R5G-S2-EU
FLT-PS2025L-B
FLT-L04016L-B
GD20-2R2G-S2-EU
GD20-0R4G-2-EU
FLT-P04006L-B
FLT-L04006L-B
GD20-0R7G-2-EU
GD20-1R5G-2-EU
FLT-P04016L-B
FLT-L04016L-B
GD20-2R2G-2-EU
GD20-004G-2-EU
FLT-P04032L-B
FLT-L04032L-B
GD20-5R5G-2-EU
GD20-7R5G-2-EU
FLT-P04045L-B
FLT-L04045L-B
GD20-0R7G-4-EU
FLT-P04006L-B
FLT-L04006L-B
GD20-1R5G-4-EU
GD20-2R2G-4-EU
GD20-004G-4-EU
FLT-P04016L-B
FLT-L04016L-B
GD20-5R5G-4-EU
GD20-7R5G-4-EU
FLT-P04032L-B
FLT-L04032L-B
GD20-011G-4-EU
GD20-015G-4-EU
FLT-P04045L-B
FLT-L04045L-B
GD20-018G-4-EU
GD20-022G-4-EU
FLT-P04065L-B
FLT-L04065L-B
GD20-030G-4-EU
GD20-037G-4-EU
FLT-P04100L-B
FLT-L04100L-B
GD20-045G-4-EU
GD20-055G-4-EU
FLT-P04150L-B
FLT-L04150L-B
GD20-075G-4-EU
GD20-090G-4-EU
FLT-P04240L-B
FLT-L04240L-B
GD20-110G-4-EU
Note:
1. The input EMI meet the requirement of C2 after adding input filters.
2. Above options are external, the customer should indicate when purchasing.
C.7 Brake components
C.7.1 Select the brake components
It is appropriate to use brake resistor or brake unit when the motor brakes sharply or the motor
