INVT Goodrive100-PV Series User Manual

Goodrive100-PV Series Solar Pumping VFD Dimension drawings
84
Model
W1
W2
H1
H2
D1
D2
Installation
hole (d)
GD100-075G-4-PV
282.0
160.0
560.0
542.4
238.0
138.0
9
GD100-090G-4-PV
338.0
200.0
554.0
534.0
326.2
--
9.5
GD100-110G-4-PV
338.0
200.0
554.0
534.0
326.2
--
9.5
GD100-132G-4-PV
500.0
360.0
870.0
850.0
360.0
--
11
GD100-160G-4-PV
500.0
360.0
870.0
850.0
360.0
--
11
GD100-185G-4-PV
500.0
360.0
870.0
850.0
360.0
--
11
GD100-200G-4-PV
500.0
360.0
870.0
850.0
360.0
--
11
(b) Flange installation
Dimensions in flange installation (unit: mm)
Model
W1
W2
W3
W4
H1
H2
H3
H4
D1
D2
Installation
hole
Nut
specs
GD100-004G-4-PV
170.2
131
150
9.5
292
276
260
6
167
84.5
6
M5
GD100-5R5G-4-PV
170.2
131
150
9.5
292
276
260
6
167
84.5
6
M5
GD100-7R5G-4-PV
191.2
151
174
11.5
370
351
324
12
196.3
113
6
M5
GD100-011G-4-PV
191.2
151
174
11.5
370
351
324
12
196.3
113
6
M5
GD100-015G-4-PV
191.2
151
174
11.5
370
351
324
12
196.3
113
6
M5
GD100-1R5G-2-PV
170.2
131
150
9.5
292
276
260
6
167
84.5
6
M5
GD100-2R2G-2-PV
170.2
131
150
9.5
292
276
260
6
167
84.5
6
M5
GD100-004G-2-PV
191.2
151
174 11.5 370 351
324
12
196.3
113
6
M5
GD100-5R5G-2-PV
191.2
151
174
11.5
370
351
324
12
196.3
113
6
M5
