Fig. 37 Service menu overview 2/2
1) Available only for heat sources with EMS plus.
12.1 Heat pump settings
This menu contains the heat pump settings.
12.1.1 Heat transfer pump settings (PC0)
The heat transfer pump in the heat pump module pumps heated water
from the condenser in the heat pump to the hot water cylinder or directly
to the heating system, alternatively to a buffer cylinder.
DHW settings Hybrid system Fault displays
DHW system Energy:price ratio Active faults
DHW heat pump 1...2 Anti-seizing protection System alarm history
DHW Start time Heat source alarm history
ON temperature Diagnosis System information
OFF temperature Function test ...
DHW reduced Enable function tests Maintenance
ON temperature Heat pump Contact address
OFF temperature ... Reset
DHW circulation pump Heating circuit 1 ... 4 Fault history
DHW circulation pump mode ... Heat pump fault history
Start frequency DHW circ. DHW system Service displays
Thermal disinfection ... Heating circuits time prog
Therm. disinfection day Pool Time prog. DHW
Therm. disinfection time ... Solar thermal system
Max. period Solar Hours run
Extra DHW temperature ... Default settings
Daily heat-up Solar Calibration
Daily heat-up time Heat pump Room temp. sen. adj.
DHW priority ... Time correction
DHW priority on Heating circuit 1 ... 4
DHW priority for ...
Prioritise heating for DHW system
Pool settings ...
Pool module available? DHW pre-heating
Pool 3-way valve ...
Add. heater start delay Pool
Solar settings ...
Solar thermal sys installed Solar
Change solar configuration ...
Current solar configuration
Solar parameters
...
Start solar thermal system
6 720 811 136-104.1O
Menu Item Setting range Description
Stand-alone mode Yes The heat pump is turned off. Heat is only produced by the booster heater.
No Heat is produced by the heat pump and the booster heater.
Pumps ( Chapter 12.1.1)
External connections ( Chapter 12.1.2)
Max. compressor output 30 ... 100 % Limitation of the heat pump max. compressor heating output.
Fuse size 16 ... 32 A The installation must be fitted with a fuse. Here you have to indicate the installed fuse (16 | 20 | 25 | 32 A).
Manual defrosting Off The evaporator is not defrosted.
On The evaporator is defrosted automatically, as needed.
Table 23 Settings in the heat pump menu
