8 MAINTENANCE & LUBRICATION
8.1 Maintenance & Lubrication Chart
MAINTENANCE AND LUBRICATION CHART
Interval Item Section
First 50 hours
 Change Engine Oil
 Check Fan Belt Tension
 Change Hydraulic Filter
82
8.3
8.5
Daily
10 hours
 Check Engine Oil Level
 Check Safety Interlock System.
 Check Coolant Level
 Check Hydraulic Fluid Level
 Check Tyre Pressure
 Check Engine Bay for Debris
8.2
7.2
8.4
8.5
4.2
8.10
Weekly
Every 50 hours
 Check for Loose Components.
 Check for Hydraulic Leaks.
 Check Fan Belt Tension
 Check Air Filter Tell Tail Indicator *
8.10
8.10
8.3
8.8
Every 250 hours
 Change Engine Oil and Oil Filter
8.2
End of season
Every 1000 hours
 Check Battery Condition.
 Change Hydraulic Oil & Filter
 Change Air Filter Element *
 Replace Fuel Filters
 Change Hydraulic Oil and Filter
 Drain and Clean Fuel Tank
 Drain and Replace Engine Coolant
8.9
8.2
8.8
8.7
8.5
8.7
8.4
Lubricate all Grease fittings weekly (see diagram)
* Check more offten in dusty conditions
IMPORTANT
Refer to Engine Manufacturers Manual for Additinal Engine Maintenance Procedures
FLUID REQUIREMENTS
Quantity Type
A Engine Oil (with filter) 5.1 litres (1.35 US gals) 10W 30
B Hydraulic Oil (with filter) 37.9 litres (10 US gals) Greenscare 46 (ISO VG 46) Bio
Degradable Oil
C Radiator Coolant 5.2 litres (1.37 US gals) 50% Anti-Freeze
D Fuel 45.4 litres (12 US gals) No 2-D (ASTM D975) Diesel
