4.1 ENGINE SPECIFICATION
Tier 4 Engine: Kubota 18.5KW (24.8HP) @
3000 RPM, 3 cylinder (in line)
Normally Aspirated Diesel
engine, 4 stroke, water cooled,
1123cc (68.53 cu.in) with 12V
1KW electric start, 12V 40Amp
Alternator
Model: D1105-E4B-RNS-1
Maximum Speed: 3150 ± 50 RPM (No load)
Idle Speed: 1650 ± 25 RPM
Oil Sump Capacity: 5.1 litres (1.35 US gals)
Fuel: No. 2-D Diesel fuel (ASTM D975)
Tier 3b Engine: Kubota 24.5KW (32.8HP) @
3000 RPM, 3 cylinder (in line)
Turbo charged Diesel engine, 4
stroke, water cooled, 1123cc
(68.53 cu.in) with 12V 1KW
electric start, 12V 30Amp
Alternator
Model: D1105-T-E3B-RNUK-3
Maximum Speed: 3150 ± 50 RPM (No load)
Idle Speed: 1650 ± 25 RPM
Oil Sump Capacity: 5.1 litres (1.35 US gals)
Fuel: No. 2-D Diesel fuel (ASTM D975)
4.2 MACHINE SPECIFICATION
Frame construction: Heavy duty formed steel chassis
with box section frame rails.
Cutting unit drive:Fixed displacement hydraulic
motors.
Transmission: 3-wheel drive. Direct coupled
variable displacement pump to
direct coupled 200cc/rev front,
400cc/rev rear wheel motor.
Speeds:
Cutting: 0 - 9.5 km/h (0 - 5.9 mph)
FORWARD
Transport: 0 - 14 km/h (0 - 8.5 mph)
FORWARD
Reverse: 0 - 6 km/h (0 -3.7 mph)
Steering: Hydrostatic power steering, with
adjustable tilt steering wheel.
Ground pressure: 1 kg/cm
2
(14p.s.i.)
Brakes: Hydrostatic braking with hydraulic
parking brakes on front wheels.
Fuel Tank
Capacity: 45.4 litres (12 US galls)
Hydraulic Tank
Capacity: 25 litres (6.6 US galls)
Battery: Exide 093 (SAE 500)
4.3 DIMENSIONS
A Width of cut 183 cm 72 in
B Transport width 200 cm 79 in
C Overall height without ROPS 134 cm 52.7 in
D
Overall height with ROPS,
add
48 cm 19 in
E Overall Length 312 cm 123 in
F Wheel Track 132 cm 52 in
G Wheel Base 151 cm 59.75 in
H Weight of Machine (less fuel) 821 kg 1810 lb
J Weight of Cutting Unit (each) 91kg 201 lb
K
Weight of Fuel - 45.4 litres
(12 US gal)
39 kg 86 lb
SPECIFICATION 4
