Specifications
Desktop Robot JR3000
Name
Function
Pin No.
MT2
Input
MT2 Input 1
Refer to the operation manual
Auxiliary Axis Functions.
38
MT2 Input 2
37
MT2 Input 3
36
MT2 Input 4
35
MT2 Input 5
34
MT2 Input 6
33
MT2 Input 7
32
MT2 Input 8
31
Sensor Input
MT2 Z Input
29
MT2 Sensor Input
47
MT2 Sensor COM-
48
MT2 Sensor COM+
50
Output
MT2 Output 1
39
MT2 Output 2
40
MT2 Output 3
41
MT2 Output 4
42
MT2 Output 5
43
MT1 Output 6
44
Pulse Output
MT2 Pulse Output 1
26
MT2 Pulse Output 2
27
MT2 Pulse Output Common
28
Other
COM+
General Input DC+24V COM+
45
COM-
General Output COM-
46
GND
GND
30
13.4 Cable Wiring
170 551 001 “I/O-MT Optional Cord (Unit)” (3m)
Pin No.
Cord Color
Pin No.
Cord Color
Pin No.
Cord Color
1
Brown
18
Gray
35
Green
2
Red
19
White
36
Blue
3
Orange
20
Black
37
Purple
4
Yel low
21
Brown
38
Gray
5
Green
22
Red
39
White
6
Blue
23
Orange
40
Black
7
Purple
24
Yel low
41
Brown
8
Gray
25
Green
42
Red
9
White
26
Blue
43
Orange
10
Black
27
Purple
44
Yel low
11
Brown
28
Gray
45
Green
12
Red
29
White
46
Blue
13
Orange
30
Black
47
Purple
14
Yel low
31
Brown
48
Gray
15
Green
32
Red
49
White
16
Blue
33
Orange
50
Black
17
Purple
34
Yel low
Connector unit: 170 554 004 “I/O-MT connector (unit)”
