Janome JR3303N-AJ User Manual

Specifications
Desktop Robot JR3000
1 Station Occupied/Expansion Cyclic Setting x2
Score
Register Number
Relay Number
Data Input
8
100 – 107
-
I/O Input
16
-
1400 – 140F
Data Output
7
180 – 186
-
I/O Output
16
-
1C00 – 1C0F
2 Stations Occupied/Expansion Cyclic Setting x2
Score
Register Number
Relay Number
Data Input
16
100 – 10F
-
I/O Input
48
-
1400 – 142F
Data Output
15
180 – 18E
-
I/O Output
48
-
1C00 – 1C2F
1 Station Occupied/Expansion Cyclic Setting x4
Score
Register Number
Relay Number
Data Input
16
100 – 10F
-
I/O Input
32
-
1400 – 141F
Data Output
15
180 – 18E
-
I/O Output
32
-
1C00 – 1C1F
1 Station Occupied/Expansion Cyclic Setting x8
Score
Register Number
Relay Number
Data Input
32
100 – 11F
-
I/O Input
64
-
1400 – 143F
Data Output
31
180 – 19E
-
I/O Output
64
-
1C00 – 1C3F
NOTE
• The station type is a remote device station.
• The last 1 word of the output word area is used by the system area and therefore its use is
prohibited.
• Before connecting to CC-Link, always make sure that the highest controller (master unit) is
useable.
85
