RS T4F Diesel Generator
|
G220RS 23
The generating set should only be lifted using the
designated lifting points or the fork pockets
where provided.
Do not lift the unit by the alternator or engine
lifting eyes. These are designed only to carry the
weight of the specific unit (engine or alternator)
and not for the weight of the fully assembled
generating set.
Lifting
NOTE: Always ensure that lifting
equipment is rated to lift the load.
Weights are shown on the generator
rating plate on the side of the
control panel. These weights
exclude fuel, and while both the fork
pockets and lifting frame are rated
to allow lifting including fuel, the
operator needs to ensure that they
have adequate lifting capacity.
B
A
A
C
Fig 14
A A Lifting eye
(two on each side)
B Lifting eye decal
C Centre lifting eye
