18
Output Power, Continuous RMS watts,
both channels driven
250 watts @ 8 ohms / 500 watts @ 8 ohms per channel
500 watts @ 4 ohms / 1000 watts @ 4 ohms per channel
Frequency Response 5 Hz – 60 kHz, -3 dB @ 8 ohms / 5 Hz - 45 kHz, -3 dB @ 8 ohms
Peak Output Current 35 amps / 40 amps
Dynamic Range 117 dBa / 120 dBa
Load Impedance Range 3 ohms -16 ohms
Input Impedance 48 k ohms
THD and Noise, 0.1 watts to Maximum Output < 0.05%, Typically .006% @ 1kHz / < 0.1%, Typically .01% @ 1kHz
Dampening Factor @ 1 kHz > 1000 / >1000
Gain Structure Preamplifier Section 14 dB, Amplifier Section 26 dB
Volume Control Range 99.5 dB
Volume Control Resolution 0.5 dB +/- 0.05 dB Over Entire Range
Common Mode Rejection Ratio > 85 dB, 20 Hz to 20 kHz
Inputs
2 pair Balanced (XLR), 2 pair Unbalanced (RCA)
1 pair Unbalanced (RCA), Unity Gain (Bypass)
Outputs
1 pair Balanced (XLR), 1 pair Unbalanced (RCA)
1 pair CE-Approved Speaker Wire Clamp
Power Consumption Idle - 25 watts, Max - 1000 watts / Idle - 35 watts, Max - 2000 watts
Power Supply
Switch Mode (SMPS) / Switch Mode (SMPS) with active power factor correction
(PFC) and universal AC input voltage
Amplifier Weight
41 lbs. / 18.6 kg / 44 lbs. / 20 kg
Overall Amplifer Dimensions (H) x (W) x (D)
5.3” x 15.5” x 15.6”
135mm x 394mm x 396mm
