Jetson Atlas User Manual

24
2.2 Repositioning the Seat
WHEN A RIDER IS SITTING ON THE SEAT AND HAS A FOOT ON THE PEDAL AT THE LOWEST PEDAL ROTATION POINT,
THERE SHOULD BE A SMALL BEND IN THE KNEE. LEGS SHOULD NEVER BE FULLY EXTENDED DURING PEDALING.
TO RAISE OR LOWER THE SEAT:
1. PULL OPEN THE LATCH ON THE SEAT CLAMP.
2. RAISE OR LOWER THE SEAT TO THE DESIRED POSITION, MAKING SURE NOT TO RAISE THE SEAT HIGH ENOUGH THAT THE
"MINIMUM INSERTION" MARK COMES INTO VIEW ABOVE THE CLAMP. IF THE SEAT CLAMP IS TOO TIGHT FOR THE POST TO
SLIDE UP AND DOWN EASILY, WIDEN THE CLAMP OPENING BY TURNING THE CLAMP KNOB COUNTERCLOCKWISE.
3. WHILE HOLDING THE SEAT IN PLACE, CLOSE THE CLAMP LATCH AND, IF NECESSARY, RETIGHTEN THE CLAMP KNOB BY
TURNING IT CLOCKWISE.
MINIMUM INSERTION MARK
SEAT CLAMP
CLAMP LATCH
CLAMP KNOB
(opposite side- not shown)
