Jetson Light Rider User Manual

23
1.5 Attaching the Seat
1. PULL OPEN THE LATCH ON THE SEAT CLAMP.
2. LOCATE THE "MINIMUM INSERTION" MARK ENGRAVED NEAR THE BOTTOM OF THE SEAT POST. LOWER THE SEAT POST
THROUGH THE CLAMP AND INTO THE SEAT TUBE. IF THE CLAMP OPENING IS TOO NARROW TO RECEIVE THE POST,
YOU CAN WIDEN IT BY TURNING THE KNOB COUNTERCLOCKWISE WHILE HOLDING THE LATCH STEADY.
3. SLIDE THE SEAT POST DOWN AT LEAST UNTIL THE "MINIMUM INSERTION" MARK IS NO LONGER VISIBLE. ADJUST
THE SEAT HEIGHT TO RIDER’S COMFORT AND ROTATE IT SO THAT THE NARROW END IS AT THE FRONT, IN LINE WITH
THE FRAME.
"MINIMUM INSERTION" MARK
SEAT POST
BIKE FRAME
CLAMP KNOB
*OPPOSITE
SIDE OF BIKE
SEAT CLAMP
SEAT
SEAT TUBE
SEAT CLAMP LATCH
