14 - General Information
ENGINE SPECIFICATIONS
40, 50 Models
Displacement 49.7cu. in. (815 cc)
Engine Type Four-Cycle, In-line, 3 Cylinder
Dual Overhead Cam, Electronic Fuel Injection
Full Throttle Operating Range 40 - 5200 to 5800 RPM
40 - 5600 to 6200 RPM
(3)
50 - 5900 to 6500 RPM
Power
(1)
(1) Rated following the standards of ICOMIA 28.83, ISO 3046, and NMMA.
40 - 40 HP (29.4 kw) @ 5500 RPM
40 - 40 HP (29.4 kw) @ 5900 RPM
(4)
50 - 50 HP (36.8 kw) @ 6200 RPM
Idle RPM in Gear
(2)
(2) Emission Control Information.
850 ± 50
Ignition Timing – Idle
(2)
W.O.T.
Not Adjustable
Not Adjustable
Exhaust Emission Control System:
per SAE J1930
(2)
SFI
Fuel Requirements
(2)
87 Pump Posted AKI (90 RON) – Refer to Fuel and Oil
Crankcase – Oil
Capacity
Filter
Evinrude/Johnson Ultra
™ 4-Stroke synthetic blend oil – Refer to Fuel and Oil
2.3 qts. (2.2 Liters)
See your Dealer
Warning Signals Engine Overheat and Low Oil Pressure
Ignition Features
S.L.O.W.™
Starting Remote electric
Battery, Minimum
(3)
(3) Not supplied in all marketing areas.
(4) European model only (Model number BJ40PL4SO).
500 CCA (620 MCA) with 90 minutes reserve capacity
OR 60 ampere-hour, 12 volt
Spark Plug
(2)
Torque
Refer to ECI Label
11 to 14 ft. lbs. (15 to 19 N
·m)
Fuse Refer to
Fuses
Fuel Line Filter P/N 5030702 – Refer to Fuel Line Filter
Alternator 13-Amp, Fully Regulated
Gearcase - Lubricant
Capacity
Evinrude/Johnson Ultra-HPF™
gearcase lube
21 fl. oz. (610 ml)
Pwr. Trim/Tilt - Fluid Capacity 12 fl. oz. (350 ml)
Propeller
(3)
40 - 11 1/2 x 13 in. (29.2 x 33.0 cm)
50 - 11 3/8 x 14 in. (28.9 x 35.6 cm)
Weight 243 lbs. (110 kg)
Sound at Driver’s Ear
(LpA) ICOMIA 39.94
40 - 76.7 dB(A)
50 - 78.6 dB(A)
Transom Height 19 1/2 to 20 in. (49.5 to 50.8 cm)
