– 54 –
18) Adjustment of parallel sewin
1. ecure the corner knife holder with setscrew cso that the opening
amount of the holder is set to approx. 25 mm.
2. Insert the corner knife in the groove section of the corner knife
holder and secure the blade position where the width of the blade tip
attains an approximate needle size G. In this position, turn the
eccentric pin in the direction of the arrow and fix it.
After completion of the setting described above, perform trial sewing
with use of sewing material.
19) Fine adjustments for stitches
1. To adjust the cut section length , loosen the eccentric pin and
move the corner knife in the direction of the arrow .
(Caution) During the above-mentioned moving adjustments, the
blade tip section should be positioned where it is
covered.
2. For the adjustment of the cut section angle , loosen the setscrew
and adjust the amount of opening of the corner knife holder .
Adjustment Procedures Results of Improper Adjustment
To Next Page
