– 56 –
1. Adjustment of pedal ball plunger
(1) Loosen the pedal ball plunger fixing nut and adjust the position of
the pedal ball plunger in the arrow direction (A or B).
o The pedal click is strengthened when the pedal ball plunger is
moved in Direction A.
o The pedal click is weakened when the pedal ball plunger is moved
in Direction B.
(2) Use the pedal ball plunger fixing nut for fixing.
(Caution) 1. The pedal ball plunger is made of plastics. Be aware
that tightening the plunger fixing nut excessively
may damage the plunger.
2. Adjust the main body of the pedal ball plunger so
that it is not protruded from the end face of the pedal
lever .
3. The plunger ball only is allowed to be protruded
from the end face of the pedal lever .
2. Adjustment of the pedal lever support plate
(1) To prevent the pedal lever from rattling in the direction of the
arrow, loosen the pedal lever support plate setscrew and move
the pedal lever support plate in the direction of the arrow for
adjustment.
(Caution) 1. A pedal return error may occur if the pedal lever
does not move smoothly throughout the stroke range.
2. The pedal click is weakened if the pedal lever has a
rattling problem in the arrow direction (A or B).
3. Adjustment of ball plunger hole position
(1) Loosen the pedal lever fixing screw and align the mounting tap
of the pedal ball plunger of the pedal lever with the plunger
hole of the pedal base .
Adjustment Procedures Results of Improper Adjustment
To Next Page
