– 2 –
3. Preparation for operation
3-1. Installation of the sewing machine
3. Attach four rubber cushions
❷
to four corners
of the table socket.
4. Put oil pan
❸
on the rubber cushions.
5. Secure machine head hinge seat
❶
on the
table with nails (two pieces)
❹
as illustrated in
the gure.
6. Attach the hinge to the machine head. Put the
hinge on the hinge rubber seats.
❹
❶
❸
❷
1. To prevent possible accidents caused by the
full of the sewing machine, perform the work
by two persons or more when the machine is
moved.
2. Place the sewing machine on a horizontal and
plane place when placing it and do not place
any protruding thing such as a screwdriver or
the like.
Never hold the handwheel since it
rotates.
To Next Page
