– 4 –
After the completion of adjustment of
the oil amount, run the sewing ma-
chine for 30 seconds or more. Then,
check whether the hook is adequately
lubricated.
3-4. Adjusting the oil amount in the hook
Adjust the oil amount with oil amount adjustment
screw
❶
that is located on the front bushing of
hook driving shaft. The oil amount is increased
by turning adjustment screw
❶
clockwise (+) or
decreased by turning it counterclockwise (-).
❶
IncreaseDecrease
Apply an appropriate amount of oil to the portion
indicated with an arrow.
(Be sure to apply an appropriate amount of oil
once a day.)
WARNING :
To protect against possible personal injury due to abrupt start of the machine, be sure to start the
following work after turning the power o and ascertaining that the motor is at rest.
To Next Page
