– 24 –
(7) Lubrication
Standard Adjustment
3) Hook oil amount
Condition:
After 30 seconds of idling, there shall be
generation of oil splashes in 5 seconds.
oil splashes
Oil amout
decreases
Oil amount
increases
+
—
A sheet of paper
Hook
Upper engraved
maker line
Lower engraved maker line
1) Lubrication system 2) How to clean the filter section
22mm
Circulation tube
Oil tank
Bottom cover
Plunger
