– 3 –
2-5. Attaching the button tray assembly
2-6. Threading the machine
Thread the machine head in the order of
1
to
@1
as shown
in the illustration given above. Then, pass the
thread through the needle eye from the front for approximately 60 to 70 mm as you depress nipper releasing
knurled thumb nut
A
.
* Standard needle is TQ X 1 #16.
1) Loosen screw
2
and remove thread gu
ide
3
.
2)
Place needle bar guard
1
under thread gu
ide
3
and attach thread guide
3
so that lever
4
comes to the center of
it at the start of the ma-
chine.
3) Fix the cover with screw
2
.
2-4. Attaching the needle bar cover
WARNING :
To protect against possible personal injury due to abrupt start of the machine, be sure to start the
following work after turning the power off and ascertaining that the motor is at rest.
WARNING :
To protect against possible personal injury due to abrupt start of the machine, be sure to start the
following work after turning the power off and ascertaining that the motor is at rest.
Insert the posts of button tray
1
in hole on the right
of the machine sub-base and tighten each setscrew
2
. If it is difcult for the operator to pick up the but-
tons on the r
ight side, change it to hole
3
on the left
side.
1
2
1
2
4
3
3
1
2
5
6
7
8
9
!3
!1
!2
!6
!4
!5
!9
!7
!8
A
@0
@1
!0
4 3
