37
Stitch choice Over lock 2 needles, 2 loopers: 4 thread overlock with integrated safety seam
1 needle, 2 loopers: 3 thread overlock, atlock roll hem
1 needle, 1 looper: 2 thread overlock, atlock roll hem
2 needles, 1 looper: 3 thread super stretch
Needle system SCHMETZ 130/705 H or JLx2
Seam width 5-7 mm (3/2 thread overlock)
7-9 mm (4 thread overlock / 3/2 thread overlock / 3 thread super stretch)
Stitch length 1-4 mm
Differential feed No puckering 0.7 - N
No waving or uting in knits N - 2
Presser foot lifter 5 mm
Handwheel Rotates forwards
Sewing speed Up to 1,500 sti/min
Weight 9 kg
Dimensions 330 (W) × 280 (D) × 310 (H) mm
Foot control model No. YC-482 (USA and Canada only)
YC-483N (220-240V)
We reserve the right to make changes in the interest of technical progress.
Technical data
