– 33 –
oIf the throat plate support comes
in single sided contact with the
throat plate or does not come in
contact with it, the throat plate will
vibrate severely.
1) Loosen setscrews and adjust so that throat plate support should
not come in single-sided contact but come in uniform contact with
throat plate using setscrews .
o If the feed mechanism cover is
not fully pressed and the cover
rises, oil leakage will be caused.
1) Loosen setscrew and press feed mechanism cover presser in
the direction of arrow.
2) Press feed mechanism cover and tighten setscrew so that the
feed mechanism cover should not rise.
(Caution) Check that feed mechanism cover is pressed so that it
should not rise.
Adjustment Procedure Results of Improper Adjustment
Adjustment Procedure Results of Improper Adjustment
