Juniper SRX300 User Manual

Meet the SRX300
The Juniper Networks
®
SRX300 Firewall provides next-generation security, routing, switching, and WAN connectivity in
a small desktop device. The SRX300 features eight 1GbE ports, including six RJ-45 network ports, and two small form-factor
pluggable (SFP) transceiver ports. It also has a USB 3.0 port (type A), and a console port (RJ-45+mini USB).
Install the SRX300 in a Rack
IN THIS SECTION
What’s in the Box? | 2
What Else Do I Need? | 2
Rack It | 3
You can install the SRX300 on a desktop, on a wall, or in a rack. This procedure shows you how to install it in a rack.
What’s in the Box?
•
SRX300 Firewall
•
A power cord appropriate for your geographic location
•
A USB cable
What Else Do I Need?
DB-9 to RJ-45 cable or a DB-9 to RJ-45 adapter with a CAT5E copper cable—We no longer include a DB-9 to RJ-45 cable
or a DB-9 to RJ-45 adapter with a CAT5E copper cable as part of the device package. If you require a console cable, you
can order it separately with the part number JNP-CBL-RJ45-DB9 (DB-9 to RJ-45 adapter with a CAT5E copper cable).
2

Juniper SRX300 Specifications

General

USB 2.0 ports quantity	1
Connectivity technology	Wired
SFP module slots quantity	2
Ethernet LAN (RJ-45) ports	6
Internal memory	4000 MB
Flash memory	8000 MB
Storage media type	Flash
Power consumption (typical)	15.4 W
Noise level	0 dB
Heat dissipation	85 BTU/h
Concurrent connections	64000
Mean time between failures (MTBF)	389820 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Routing protocols	BGP, CLNS, IS-IS, OSPF, RIP-1, RIP-2
Number of users	50 user(s)
Quality of Service (QoS) support	Yes
Firewall throughput	1000 Mbit/s
Mobile VPN IPSec	250
IPS/IDS throughput	100 Mbit/s
Harmonized System (HS) code	85176990

Weight and Dimensions

Weight	1980 g
Dimensions (WxDxH)	320.8 x 34.7 x 191 mm
