4. Start your asynchronous terminal emulation application (such as Microsoft Windows HyperTerminal) and select the
appropriate COM port to use (for example, COM1).
5. Verify that the serial port settings are set to the default:
•
Baud rate—9600
•
Parity—N
•
Data bits—8
•
Stop bits—1
•
Flow control—none
NOTE: You can also connect to the SRX300 using a mini-USB console port. See the SRX300 Hardware Guide.
Perform Initial Configuration
1. Login as the root user and start the CLI. You don't need a password if you're running the factory default.
login: root
root@%cli
root>
NOTE: You can view the factory-default settings with the show configuration operational mode command.
2. Enter configuration mode.
root> configure
[edit]
root#
3. Since you're doing the initial configuration manually, you'll need to remove ZTP from the configuration. This stops the
periodic log messages that report on ZTP status.
Set the root authentication password and commit the change to deactivate ZTP.
[edit]
root# delete chassis auto-image-upgrade
root# delete system phone-home
root# set system root-authentication plain-text-password
New password: password
8

Juniper SRX300 Specifications

General

USB 2.0 ports quantity	1
Connectivity technology	Wired
SFP module slots quantity	2
Ethernet LAN (RJ-45) ports	6
Internal memory	4000 MB
Flash memory	8000 MB
Storage media type	Flash
Power consumption (typical)	15.4 W
Noise level	0 dB
Heat dissipation	85 BTU/h
Concurrent connections	64000
Mean time between failures (MTBF)	389820 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Routing protocols	BGP, CLNS, IS-IS, OSPF, RIP-1, RIP-2
Number of users	50 user(s)
Quality of Service (QoS) support	Yes
Firewall throughput	1000 Mbit/s
Mobile VPN IPSec	250
IPS/IDS throughput	100 Mbit/s
Harmonized System (HS) code	85176990

Weight and Dimensions

Weight	1980 g
Dimensions (WxDxH)	320.8 x 34.7 x 191 mm
