Juniper SRX300 User Manual

Power On
Now that you’ve installed your SRX300 in the rack, you’re ready to connect it to power.
1. Wrap and fasten one end of the electrostatic discharge (ESD) grounding strap around your bare wrist, and connect the
other end to a site ESD point.
2. Plug the DC connector end of the power cable into the power connector at the back of the SRX300.
3. Plug the AC adapter end of the power cable into the power supply adapter.
4. If the AC power source outlet has a power switch, turn it off.
5. Plug in the power cord to the AC power outlet.
6. If the AC power outlet has a power switch, turn it on.
The SRX300 powers up as soon as you connect it to power. When the STAT LED on the front panel is lit solid green,
the SRX300 is ready to use.
Step 2: Up and Running
IN THIS SECTION
SRX300 Provisioning Options | 6
Initial Configuration Using the CLI | 6
Now that the SRX300 is powered on, let’s do some initial configuration to get it up and running on the network.
5

Juniper SRX300 Specifications

General

USB 2.0 ports quantity	1
Connectivity technology	Wired
SFP module slots quantity	2
Ethernet LAN (RJ-45) ports	6
Internal memory	4000 MB
Flash memory	8000 MB
Storage media type	Flash
Power consumption (typical)	15.4 W
Noise level	0 dB
Heat dissipation	85 BTU/h
Concurrent connections	64000
Mean time between failures (MTBF)	389820 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Routing protocols	BGP, CLNS, IS-IS, OSPF, RIP-1, RIP-2
Number of users	50 user(s)
Quality of Service (QoS) support	Yes
Firewall throughput	1000 Mbit/s
Mobile VPN IPSec	250
IPS/IDS throughput	100 Mbit/s
Harmonized System (HS) code	85176990

Weight and Dimensions

Weight	1980 g
Dimensions (WxDxH)	320.8 x 34.7 x 191 mm
