AV-27D502
32 No. 51797C
CONTENTS
USING P.W. BOARD & REMOTE CONTROL UNIT ................................................................................. 32
EXPLODED VIEW PARTS LIST ............................................................................................................... 32
EXPLODED VIEW .................................................................................................................................... 33
PRINTED WIRING BOARD PARTS LIST (AV-27D502/AR)
MAIN PW BOARD ASS'Y .....................................................................................................................................34
CRT SOCKET PW BOARD ASS’Y .......................................................................................................................37
FRONT CONTROL PW BOARD ASS’Y ............................................................................................................... 38
FRONT AV INPUT PW BOARD ASS’Y ................................................................................................................ 38
PIP PW BOARD ASS’Y ........................................................................................................................................ 38
AV SELECTOR PW BOARD ASS’Y .....................................................................................................................39
REMOTE CONTROL UNIT PARTS LIST (RM-C301G-2A).............................................................................. 41
DIFFERENCE PARTS LIST BETWEEN AV-27D502/AR AND AV-27D502/AS ................................................. 42
PACKING / PACKING PARTS LIST ..................................................................................................................... 43
EXPLODED VIEW PARTS LIST
!
Ref.No. Part No. Part Name Description Local
USING P.W. BOARD & REMOTE CONTROL UNIT
MAIN PW BOARD SGC-1002A-M2 SGC-1001A-M2
CRT SOCKET PW BOARD SGC-3002A-M2 SGC-3001A-M2
FRONT CONTROL PW BOARD SGC-8501A-M2
FRONT AV INPUT PW BOARD SGC-8601A-M2
PIP PW BOARD SGC0P001A-M2
AV SELECTOR PW BOARD SGC0S001A-M2
REMOTE CONTROL UNIT RM-C301G-2A
AV-27D502/AR AV-27D502/AS
P.W.B ASS’Y
Model
! L01 CE41329-00DJB DEG COIL
! T1502 QQH0100-001 FBT Within MAIN PWB
! V01 A68ADT25X01 CRT Inc. DY(AV-27D502/AR)
! V01 A68QDN891X001 CRT Inc. DY(AV-27D502/AS)
! 1 QMPD200-200-JC POWER CORD CN10PW Within MAIN PWB
2 LC30191-002A-A REMOCON WINDOW
3 CM48006-007-C JVC MARK
4 LC20217-005B-A CONTROL KNOB
5 A48457-4-S SPRING
6 WJY0016-001A BRAIDED WIRE
7 WJY0013-004A BRAIDED WIRE
! 8 CEBSS12D-04KJ2 SPEAKER (x2) SP01, SP02
! 9 LC10883-001C-A CHASSIS BASE
! 10 LC20899-003A-A TERMINAL BOARD
11 QYSBSB3010Z TAPPING SCREW (x4)
12 WJX0014-002A E-COAXIAL ASSY
! 13 LC10277-003A-A REAR COVER (AV-27D502/AR)
! 13 LC10277-003B-A REAR COVER (AV-27D502/AS)
14 QYSBSFG4016Z TAPPING SCREW (x12)
15 LC30684-005A-A BBE LABEL (AV-27D502/AR)
! 16 LC31139-001A-A RATING LABEL (AV-27D502/AR)
! 16 GQ30032-001A-A RATING LABEL (AV-27D502/AS)
! 17 LC20106-001D-A CORD CLAMP
18 QYSBSB4012Z TAPPING SCREW (x8)
19 QYSBSBG3010Z TAPPING SCREW (x5)
! 100 LC10964-002B-A FRONT CABI ASSY Inc. No. 101-102 (AV-27D502/AR)
! 100 LC10964-002C-A FRONT CABI ASSY Inc. No. 101-102 (AV-27D502/AS)
101 LC20409-005A-A DOOR (AV-27D502/AR)
101 LC20409-005B-A DOOR (AV-27D502/AS)
102 CM48229-00A-C DOOR LATCH (AV-27D502/AR)
102 PU60109 CATCHER (AV-27D502/AS)
To Next Page
