JVC AV-27D502/R User Manual

2-16 No.51797C
FRONT CONTROL AND FRONT AV INPUT PWB CIRCUIT DIAGRAMS
AV-27D502
-FRONT CONTROL-
-FRONT AV INPUT-
: NON MOUNT
X
NOTE
KEY2
1.5k
R708
UN2112-X
SWITCH
Q701
3.3k
R707
SLR-342VR3F
D701
QSW0619
-003Z
S706
REMOCON
T_LED
P_LED
STB5V
UN2112-X
SWITCH
Q702
560
R709
47/25
C701
KEY1
QSW0619
-003Z
S701
GP1U281Q
REMOCON
RECEIVER
IC701
OUTGND
QSW0619
-003Z
S705
QSW0619
-003Z
S704
QSW0619
-003Z
S702
QSW0619
-003Z
S703
4.7k
R702
X
R701
15k
R703
4.7k
R705
X
R704
15k
R706
QJB003-074826
CN007
(RED)
7
POWER VOL+ VOL- CH+ CH- MENU
FRONT CONTROL PWB ASS'Y
SGC-8501A-M2
TO MAIN
PWB CN007
QNN0281-003
J401
QNN0281-002
J402
QQR1199-001
LC401
QNN0282-001
J403
75
R401
220k
R402
220k
R403
BW
C401
1/50
C402
1/50
C403
XY401
XY402
QJB003-054010
CN006
V
L
6
R
FRONT AV INPUT PWB ASS'Y
SGC-8601A-M2
V3
V3_GND
L3
R3
A_GND
TO
AV SELECTOR
PWB CN006
INPUT3
(FRONT)
5V 5V
0.2V
4.9V
5V
5V
1.7V
5V
