AV-27D502
No. 51797 41
DIFFERENCE PARTS LIST BETWEEN AV-27D502/R AND AV-27D502/S
The picture tubes used for the models AV-27D502/R and AV-27D502/S are difference. The electrical parts are also
difference according to the PICTURE TUBE.
In the DIFFERENCE PARTS LIST BETWEEN AV-27D502/R and AV-27D502/S, only difference points between these
models are written. For other parts not mentioned in the list, please refer to the PARTS LIST(P34 – P40) for the
AV-27D502/R.
Symbol
No.
!
Part Name
AV-27D502
/R AV-27D502/S
SAC-1507A-M2 SAC-1506A-M2 MAIN PWB
R1404 QRE121J-100Y (10Ø, 1/2W, J) — C R
! L1511 QQR1027-002 QQR1027-004 LINIARITY COIL
! L1521 QQLZ026-430 (43µH) QQLZ026-880 (88µH) HEATER CHOKE
! C1510 QFZ0196-352 (3500pF,1.5kVH,±3%) QFZ0196-452 (4500pF,1.5kVH,±3%) MPP CAP.
CRT SOCKET PW BOARD ASS'Y (SAC-3506A-M2)
! Symbol No. Part No. Part Name Description Local
RESISTOR
R3354-56 NRSA63J-221X MG R 220Ø 1/16W J
R3357-59 NRSA63J-101X MG R 100Ø 1/16W J
R3360-62 QRZ0111-152 C R 1.5kØ 1/2W K
R3363-65 QRG029J-103 OM R 10kØ 2W J
R3366-68 NRSA63J-182X MG R 1.8kØ 1/16W J
R3372-74 NRSA63J-221X MG R 220Ø 1/16W J
R3375-77 NRSA63J-0R0X MG R 0.0Ø 1/16W J
R3381 QRE121J-394Y C R 390kØ 1/2W J
R3391 NRSA63J-152X MG R 1.5kØ 1/16W J
R3392 NRSA63J-392X MG R 3.9kØ 1/16W J
R3393-95 NRSA63J-102X MG R 1kØ 1/16W J
CAPACITOR
C3354-55 NDC31HJ-331X C CAP. 330pF 50V J
C3356 NDC31HJ-391X C CAP. 390pF 50V J
C3357 QETN1CM-107Z E CAP. 100µF 16V M
C3382 QCZ0121-102 C CAP. 1000pF 3000V Z
C3391 QETN1AM-227Z E CAP. 220µF 10V M
C3392 NDC31HJ-101X C CAP. 100pF 50V J
COIL
L3381 QQL244K-101Z PEAKING COIL 100µH K
DIODE
D3391 1SS133-T2 SI.DIODE
TRANSISTOR
Q3351-53 2SC4544-LB SI.TRANSISTOR
Q3391 2SA933AS/QR/-T SI.TRANSISTOR
OTHERS
! SK3351 QNZ0464-001 C.R.T.SOCKET
DIFFERENCE PARTS LIST
MAIN PWB
-------------------------------------------------------------------------------------------------------------------------------------
CRT SOCKET PWB
Part No.
Symbol
No.
!
Part Name
AV-27D502
/R AV-27D502/S
SAC-3507A-M2 SAC-3506A-M2 CRT SOCKET PWB
Part No.
