JVC AV-27D502/R User Manual

! Symbol No. Part No. Part Name Description Local ! Symbol No. Part No. Part Name Description Local
AV-27D502
36 No. 51797
CAPACITOR
C1938 QETM1EM-228 E CAP. 2200µF 25V M
C1939 QCB32HK-152Z C CAP. 1500pF 500V K
C1942 QEHR1HM-105Z E CAP. 1µF 50V M
C1943 QETN1CM-108Z E CAP. 1000µF 16V M
C1948 QETN1EM-476Z E CAP. 47µF 25V M
C1951 QETN1CM-477Z E CAP. 470µF 16V M
C1971 QETN1CM-107Z E CAP. 100µF 16V M
C1972 QETN1EM-476Z E CAP. 47µF 25V M
C1973 QETN1HM-106Z E CAP. 10µF 50V M
! C1998-99 QCZ9074-103 C CAP. 0.01µF 125V M
TRANSFORMER
T1501 CE42034-002 H.DRIVE TRANSF.
! T1502 QQH0092-001 FBT
! T1921 QQS0098-001 SW TRANSF.
! T1951 QQT0315-001 POWER TRANSF.
COIL
! L1001 QQL244K-560Z PEAKING COIL 56µH K
L1012 QQLZ014-R39 PEAKING COIL 0.39µH
L1021 QRN143J-0R0X C R 0.0Ø 1/4W J
L1022 QQL244K-220Z PEAKING COIL 22µH K
L1027 QRN143J-0R0X C R 0.0Ø 1/4W J
L1041 QRN143J-0R0X C R 0.0Ø 1/4W J
L1042 QQL244K-220Z PEAKING COIL 22µH K
L1101 QQL244K-470Z COIL 47µH K
L1232 QQL244K-560Z PEAKING COIL 56µH K
! L1511 QQR1027-002 LINIARITY COIL
L1512 QQLZ027-821 CHOKE COIL 820µH
! L1521 QQLZ026-430 HEATER CHOKE 43µH
L1700 QQL244K-4R7Z COIL 4.7µH K
L1810 QQL244J-100Z COIL 10µH J
L1931 QQL26AK-470Z COIL 47µH K
L1933 QQL26AK-470Z COIL 47µH K
L1937 QQL26AK-470Z COIL 47µH K
DIODE
D1101-02 MTZJ8.2C-T2 ZENER DIODE
D1305-10 1SS133-T2 SI.DIODE
D1352 MTZJ9.1C-T2 ZENER DIODE
D1353 1SS133-T2 SI.DIODE
D1401 1SR35-400A-T2 SI.DIODE
D1431 1SR35-400A-T2 SI.DIODE
D1432 1SS133-T2 SI.DIODE
D1501 RH3G-F1 SI.DIODE
D1502 RU3AM-LFC4 SI.DIODE
D1521 RH1S-T3 SI.DIODE
D1523 RGP10J-5025-T3 SI.DIODE
D1524 RGP10J-5025-T3 SI.DIODE
D1525-26 1SS81-T5 SI.DIODE
D1527 1SR124-400A-T2 SI.DIODE
D1529 MTZJ5.1C-T2 ZENER DIODE
! D1531 MA4068N/Z1/-T2 ZENER DIODE
D1535 1SS133-T2 SI.DIODE
D1537 1SR35-400A-T2 SI.DIODE
D1601 MTZJ9.1C-T2 ZENER DIODE
D1603 MTZJ9.1C-T2 ZENER DIODE
D1606 MTZJ9.1C-T2 ZENER DIODE
D1701 1SS133-T2 SI.DIODE
D1706-10 MTZJ8.2C-T2 ZENER DIODE
D1721-22 1SS133-T2 SI.DIODE
D1723-24 MTZJ5.6B-T2 ZENER DIODE
D1800 1SS81-T2 SI.DIODE
D1801 1SS133-T2 SI.DIODE
D1810 MTZJ8.2C-T2 ZENER DIODE
D1811 1SS133-T2 SI.DIODE
! D1901 D3SBA60 DIODE BRIDGE
DIODE
D1910 MA700A-T2 SI.DIODE
! D1911 RGP10J-5025-T3 SI.DIODE
! D1912 RGP10J-5025-T3 SI.DIODE
! D1913 RGP10J-5025-T3 SI.DIODE
D1914 1SS133-T2 SI.DIODE
D1915 SARS01-T2 SI.DIODE
D1917 MTZJ30A-T2 ZENER DIODE
D1918 MTZJ5.1C-T2 ZENER DIODE
D1920 1SS133-T2 SI.DIODE
D1931 RU30A-F1 SI.DIODE
D1933 RU3YX-LFC4 SI.DIODE
D1935 RU3YX-LFC4 SI.DIODE
D1937 RGP10J-5025-T3 SI.DIODE
D1941 MTZJ33A-T2 ZENER DIODE
D1945 1SS133-T2 SI.DIODE
D1952-53 1SS133-T2 SI.DIODE
D1954-57 1SR35-400A-T2 SI.DIODE
D1972 MTZJ15C-T2 ZENER DIODE
D1973 1SS133-T2 SI.DIODE
TRANSISTOR
Q1011 2SC5083/L-P/-T SI.TRANSISTOR
Q1021 2SC2412K/QR/-X SI.TRANSISTOR
Q1024 2SC2412K/QR/-X SI.TRANSISTOR
Q1025 2SA1037AK/QR/-X SI.TRANSISTOR
Q1041 2SA1037AK/QR/-X SI.TRANSISTOR
Q1131 2SC2412K/QR/-X SI.TRANSISTOR
Q1232-33 2SC2412K/QR/-X SI.TRANSISTOR
Q1352 2SC2412K/QR/-X SI.TRANSISTOR
Q1431 2SC2412K/QR/-X SI.TRANSISTOR
Q1501 2SC4212/Z1/ SI.TRANSISTOR
! Q1511 2SD2634-YD SI.TRANSISTOR
Q1531 2SC2785/JH/-T SI.TRANSISTOR
Q1532 2SA1037AK/QR/-X SI.TRANSISTOR
Q1700 2SC2412K/QR/-X SI.TRANSISTOR
Q1701 2SA1037AK/QR/-X SI.TRANSISTOR
Q1703 2SA1037AK/QR/-X SI.TRANSISTOR
Q1706 2SC2412K/QR/-X SI.TRANSISTOR
Q1711 DTC124EKA-X DIGI.TRANSISTOR
Q1810 DTC144EKA-X DIGI.TRANSISTOR
Q1941 2SC2412K/QR/-X SI.TRANSISTOR
Q1951 2SD1383K/AB/-X SI.TRANSISTOR
Q1971 2SA1208/ST/Z1-T SI.TRANSISTOR
IC
IC1101 TB1253AN I.C.(M)
! IC1401 LA7841 I.C.(MONO-ANA)
IC1701 MN1876478JL1 I.C.(MICRO-COMP)
IC1702 AT24C04-32D502 I.C.(MEMORY-OTH) (SERVICE)
IC1703 MM1437AF-X I.C.(MONO-ANA)
IC1852 AN7809F I.C.(MONO-ANA)
IC1853 AN7805F I.C.(MONO-ANA)
IC1911 STR-G6624/F8 I.C.(HYBRID)
! IC1921 SE135N I.C.(HYBRID)
OTHERS
CF1001 QAX0349-001 CERAMIC FILTER
CF1021 QAX0639-001Z CERAMIC FILTER
CF1041 QAX0642-001Z CERAMIC FILTER
! CP1932 ICP-N75-Y I.C.PROTECT
! CP1933 ICP-N75-Y I.C.PROTECT
! CP1936 ICP-N75-Y I.C.PROTECT
! F1905 QMFZ034-5R0Z-J1 FUSE 5A
! FR1521 QRK126J-150X C R 15Ø 1/2W J
! FR1523-24 QRX029J-4R7 MF R 4.7Ø 2W J
! FR1525 QRZ9017-4R7 F R 4.7Ø 1/4W J
J1601 QNN0349-002 PIN JACK
J1810 QNS0001-001 JACK
K1401 QQR0621-002Z BEADS CORE
K1912 QQR0582-001Z BEADS CORE
