AV-27D502
No. 51797 39
! Symbol No. Part No. Part Name Description Local ! Symbol No. Part No. Part Name Description Local
RESISTOR
R0241 NRSA63J-821X MG R 820Ø 1/16W J
R0242 NRSA63J-474X MG R 470kØ 1/16W J
R0243-44 NRSA63J-103X MG R 10kØ 1/16W J
R0247 NRSA63J-101X MG R 100Ø 1/16W J
R0251 NRSA63J-471X MG R 470Ø 1/16W J
R0253 NRSA63J-681X MG R 680Ø 1/16W J
R0254 NRSA63J-391X MG R 390Ø 1/16W J
R0255 NRSA63J-681X MG R 680Ø 1/16W J
R0258 NRSA63J-101X MG R 100Ø 1/16W J
R0259 NRSA63J-222X MG R 2.2kØ 1/16W J
R0261 NRSA63J-101X MG R 100Ø 1/16W J
R0262 NRSA63J-222X MG R 2.2kØ 1/16W J
R0263 NRSA63J-471X MG R 470Ø 1/16W J
R0265 NRSA63J-102X MG R 1kØ 1/16W J
R0269 NRSA63J-681X MG R 680Ø 1/16W J
R0270 NRSA63J-102X MG R 1kØ 1/16W J
R0301-02 NRSA63J-222X MG R 2.2kØ 1/16W J
R0303-04 NRSA63J-221X MG R 220Ø 1/16W J
R0305-06 NRSA63J-0R0X MG R 0.0Ø 1/16W J
R0331-34 NRSA63J-101X MG R 100Ø 1/16W J
R0371-74 NRSA63J-103X MG R 10kØ 1/16W J
R0375-76 NRSA63J-333X MG R 33kØ 1/16W J
R0377-78 NRSA63J-472X MG R 4.7kØ 1/16W J
R0385 NRSA63J-223X MG R 22kØ 1/16W J
R0387 NRSA63J-223X MG R 22kØ 1/16W J
R0391-92 NRSA63J-221X MG R 220Ø 1/16W J
R0393-94 NRSA63J-823X MG R 82kØ 1/16W J
R0395-96 NRSA63J-221X MG R 220Ø 1/16W J
R0401 NRSA63J-183X MG R 18kØ 1/16W J
R0402 NRSA63J-223X MG R 22kØ 1/16W J
R0458 NRSA63J-333X MG R 33kØ 1/16W J
R0459 NRSA63J-183X MG R 18kØ 1/16W J
R0501-02 NRSA63J-102X MG R 1kØ 1/16W J
R0504-05 NRSA63J-102X MG R 1kØ 1/16W J
R0506 NRSA63J-221X MG R 220Ø 1/16W J
R0507-08 NRSA63J-102X MG R 1kØ 1/16W J
R0509 NRSA63J-221X MG R 220Ø 1/16W J
R0518 NRSA63J-333X MG R 33kØ 1/16W J
R0519-21 NRSA63J-750X MG R 75Ø 1/16W J
R0522-23 NRSA63J-224X MG R 220kØ 1/16W J
R0524 NRSA63J-333X MG R 33kØ 1/16W J
R0525-26 NRSA63J-750X MG R 75Ø 1/16W J
R0528-29 NRSA63J-0R0X MG R 0.0Ø 1/16W J
R0532-33 NRSA63J-224X MG R 220kØ 1/16W J
R0558-63 NRSA63J-0R0X MG R 0.0Ø 1/16W J
R0566-67 NRSA63J-331X MG R 330Ø 1/16W J
R0571 NRSA63J-101X MG R 100Ø 1/16W J
R0573 NRSA63J-272X MG R 2.7kØ 1/16W J
R0574 NRSA63J-0R0X MG R 0.0Ø 1/16W J
R0901 NRSA63J-101X MG R 100Ø 1/16W J
R0906 NRSA63J-0R0X MG R 0.0Ø 1/16W J
CAPACITOR
C0081 NCB21HK-104X C CAP. 0.1µF 50V K
C0082 QENC1HM-475Z BP E CAP. 4.7µF 50V M
C0083 QENC1HM-105Z BP E CAP. 1µF 50V M
C0084 QETN1HM-225Z E CAP. 2.2µF 50V M
C0085 NCB21HK-473X C CAP. 0.047µF 50V K
C0086 QETN1HM-474Z E CAP. 0.47µF 50V M
C0087-88 NCB21HK-104X C CAP. 0.1µF 50V K
C0089 QETN1HM-335Z E CAP. 3.3µF 50V M
C0090 QETN1HM-105Z E CAP. 1µF 50V M
C0091 QETN1HM-106Z E CAP. 10µF 50V M
C0092-93 QETN1HM-105Z E CAP. 1µF 50V M
C0094 QETN1HM-475Z E CAP. 4.7µF 50V M
C0095 QETN1HM-105Z E CAP. 1µF 50V M
C0151-52 QENC1HM-105Z BP E CAP. 1µF 50V M
C0153-54 NCB31HK-332X C CAP. 3300pF 50V K
C0155-56 NCB21HK-333X C CAP. 0.033µF 50V K
C0157-58 QETN1HM-106Z E CAP. 10µF 50V M
C0159 QETN1EM-476Z E CAP. 47µF 25V M
CAPACITOR
C0160 NCB21HK-104X C CAP. 0.1µF 50V K
C0205 QETN1HM-476Z E CAP. 47µF 50V M
C0206 NCB31HK-103X C CAP. 0.01µF 50V K
C0211 QENC1EM-106Z BP E CAP. 10µF 25V M
C0212 NDC31HJ-101X C CAP. 100pF 50V J
C0213 NDC31HJ-470X C CAP. 47pF 50V J
C0214 NDC31HJ-181X C CAP. 180pF 50V J
C0215 QETN1HM-474Z E CAP. 0.47µF 50V M
C0223 NCB31HK-103X C CAP. 0.01µF 50V K
C0226 NCB31HK-103X C CAP. 0.01µF 50V K
C0231-33 QETN1HM-106Z E CAP. 10µF 50V M
C0234 NCB31HK-103X C CAP. 0.01µF 50V K
C0235 QETN1HM-106Z E CAP. 10µF 50V M
C0236 NCB31HK-103X C CAP. 0.01µF 50V K
C0237 NCB31HK-472X C CAP. 4700pF 50V K
C0238-39 NCB31HK-103X C CAP. 0.01µF 50V K
C0241-45 NCB31HK-103X C CAP. 0.01µF 50V K
C0246 NDC31HJ-181X C CAP. 180pF 50V J
C0247-49 NCB31HK-103X C CAP. 0.01µF 50V K
C0251 QETN1HM-476Z E CAP. 47µF 50V M
C0252 NCB31HK-103X C CAP. 0.01µF 50V K
C0255 NDC31HJ-390X C CAP. 39pF 50V J
C0263 NDC31HJ-150X C CAP. 15pF 50V J
C0264 QENC1HM-474Z BP E CAP. 0.47µF 50V M
C0265 NCB31HK-103X C CAP. 0.01µF 50V K
C0309-10 NCB31HK-102X C CAP. 1000pF 50V K
C0311-12 NRSA63J-0R0X MG R 0.0Ø 1/16W J
C0331 QETN1CM-107Z E CAP. 100µF 16V M
C0332 NCB31HK-103X C CAP. 0.01µF 50V K
C0333 QETN1EM-476Z E CAP. 47µF 25V M
C0334 NCB21HK-273X C CAP. 0.027µF 50V K
C0335 QETN1HM-225Z E CAP. 2.2µF 50V M
C0336 NCB31HK-222X C CAP. 2200pF 50V K
C0337 NCB21HK-104X C CAP. 0.1µF 50V K
C0338 QETN1HM-225Z E CAP. 2.2µF 50V M
C0339 NCB31HK-222X C CAP. 2200pF 50V K
C0340 NCB21HK-104X C CAP. 0.1µF 50V K
C0343 QETN1HM-105Z E CAP. 1µF 50V M
C0344-45 QENC1HM-225Z BP E CAP. 2.2µF 50V M
C0371-72 QENC1HM-105Z BP E CAP. 1µF 50V M
C0373 QETN1EM-476Z E CAP. 47µF 25V M
C0391-92 QETN1HM-474Z E CAP. 0.47µF 50V M
C0401 QETN1CM-107Z E CAP. 100µF 16V M
C0402-03 NCF21CZ-105X C CAP. 1µF 16V Z
C0404 QFV71HJ-224Z MF CAP. 0.22µF 50V J
C0407 QETN1EM-108Z E CAP. 1000µF 25V M
C0410-11 QETN1EM-108Z E CAP. 1000µF 25V M
C0412-13 QETN1HM-105Z E CAP. 1µF 50V M
C0501-02 NCB31HK-103X C CAP. 0.01µF 50V K
C0503 QETN1HM-226Z E CAP. 22µF 50V M
C0504 QETN1EM-476Z E CAP. 47µF 25V M
C0505 QENC1HM-474Z BP E CAP. 0.47µF 50V M
C0508 QETN1HM-474Z E CAP. 0.47µF 50V M
C0509 NCB31HK-103X C CAP. 0.01µF 50V K
C0511 QETN1HM-474Z E CAP. 0.47µF 50V M
C0512-13 QETN1HM-105Z E CAP. 1µF 50V M
C0514 QETN1HM-474Z E CAP. 0.47µF 50V M
C0515 NCB31HK-103X C CAP. 0.01µF 50V K
C0520-21 QETN1HM-105Z E CAP. 1µF 50V M
C0531-32 NCB31HK-103X C CAP. 0.01µF 50V K
C0536-37 NCB31HK-103X C CAP. 0.01µF 50V K
COIL
L0202 QQL244K-150Z COIL 15µH K
L0211 QQL244K-4R7Z COIL 4.7µH K
L0242-43 QQL244K-4R7Z COIL 4.7µH K
L0261 QQL244K-150Z COIL 15µH K
DIODE
D0391-92 MTZJ10C-T2 ZENER DIODE
D0501-02 MTZJ10C-T2 ZENER DIODE
