JVC GR-DVL512U User Manual

MODEL
GR-DVL510U GR-DVL512U
ITEM
REMOTE CONTROL UNIT RM-V715U RM-V716U
TABLE OF CONTENTS
DIFFERENT TABLE ........................................................................................................................................................... 1 to 2
4. CHARTS AND DIAGRAMS (4-1 to 4-6)
4.1 MONITOR CIRCUIT BOARD ........................................................................................................................................ 4-1
4.2 LCD BL CIRCUIT BOARD ............................................................................................................................................ 4-3
4.3 JUNCTION CIRCUIT BOARD....................................................................................................................................... 4-4
4.4 JACK CIRCUIT BOARD ............................................................................................................................................... 4-5
5. PARTS LIST (5-1 to 5-5)
5.1 PACKING AND ACCESSORY ASSEMBLY <M1> ........................................................................................................ 5-1
5.2 FINAL ASSEMBLY <M2> ............................................................................................................................................. 5-3
The following table indicate main different points between models GR-DVL510U and GR-DVL512U.
1
The following table indicate different parts number between models GR-DVL510U and GR-DVL512U.
!
REF. MODEL
GR-DVL510U GR-DVL512U
NO. ITEM
11 CD ROM *LY32210-003ALY32210-009A
17 REMOTE CONTROL UNIT *LY42129-001ALY20543-002A
21 USB CABLE *QAM0324-001QAM0352-001
23 CABLE ASSY — PEAC0428-150
24 CORE FILTER — QQR0491-002
PACKING AND ACCESSORY ASSEMBLY <M1> Note: As for IB (INSTRUCTIONS), refer to sec.5.
!
REF. MODEL
GR-DVL510U GR-DVL512U
NO. ITEM
101 LOWER CASE ASSY *LY20706-003BLY20706-003C
101C COVER(JACK) *LY32099-001BLY32099-001C
102 ARM ASSY *LY20697-001ALY20697-001B
104 CASSETTE COVER ASSY *LY20704-001ALY20704-001B
107 COVER(AJUST) LY32092-010ALY32092-032A
143 SPECIAL SCREW *LY30018-084A,(X2) LY30018-084A,(X1)
146 SPECIAL SCREW *LY30018-084A,(X2) LY30018-084A,(X3)
151 SPECIAL SCREW *— LY30018-023A
158 SPECIAL SCREW *LY30018-090ALY30018-0D6A
FINAL ASSEMBLY <M2>
Notes: Mark — is not used.
Mark * reference model was also changed.
MONITOR ASSEMBLY <M5>
!
REF. MODEL
GR-DVL510U GR-DVL512U
NO. ITEM
! 500 MONITOR ASSY LYH20246-010A LYH20246-018A
510 SPACER(A) *LY30029-063A —
