SERVICE MANUAL
No. 86601
January 2001
GR-DVL510U/815U/817U/915U
SPECIFICATIONS (The specifications shown pertain specifically to the model GR-DVL310/510/815/915)
DIGITAL VIDEO CAMERA
Printed in Japan
This service manual is printed on 100% recycled paper.
COPYRIGHT © 2001 VICTOR COMPANY OF JAPAN, LTD.
GR-DVL510U/815U/817U/915U
No. 86601
JVC SERVICE & ENGINEERING COMPANY OF AMERICA
DIVISION OF JVC AMERICAS CORP.
Head office
East Coast
Midwest
West Coast
Atlanta
Hawaii
:
:
:
:
:
:
1700 Valley Road Wayne, New Jersey 07470-9976
10 New Maple Avenue Pine Brook, New Jersey 07058-9641
705 Enterprise Street Aurora, Illinois 60504-8149
5665 Corporate Avenue Cypress, California 90630-0024
1500 Lakes Parkway Lawrenceville, Georgia 30043-5857
2969 Mapunapuna Place Honolulu, Hawaii 96819-2040
(973)315-5000
(973)396-1000
(630)851-7855
(714)229-8011
(770)339-2582
(808)833-5828
JVC CANADA INC.
Head office
Montreal
Vancouver
:
:
:
21 Finchdene Square Scarborough, Ontario M1X 1A7
16800 Rte Trans-Canadienne, Kirkland, Quebec H9H 5G7
13040 Worster Court Richmond, B.C. V6V 2B3
(416)293-1311
(514)871-1311
(604)270-1311
S40895-03
Camcorder
For General
Power supply : DC 11.0 V } (Using AC Adapter)
DC 7.2 V } (Using battery pack)
Power consumption
LCD monitor off, viewfinder on : Approx. 4.3 W
LCD monitor on, viewfinder off : Approx. 5.3 W
Video light : Approx. 3.5 W
Dimensions (W x H x D) : 83 mm x 97 mm x 188 mm (3-5/16" x 3-7/8" x 7-7/16")
(with the LCD monitor closed and the viewfinder pushed down)
Weight : Approx. 610 g (1.4 lbs) (GR-DVL915)
Approx. 600 g (1.4 lbs) (GR-DVL815)
Approx. 590 g (1.3 lbs) (GR-DVL510/DVL310)
Operating temperature : 0°C to 40°C (32°F to 104°F)
Operating humidity : 35% to 80%
Storage temperature : –20°C to 50°C (–4°F to 122°F)
Pickup : 1/4" CCD
Lens : F 1.8, f = 3.6 mm to 36 mm, 10:1 power zoom lens
Filter diameter : ø37 mm
LCD monitor : 3.5" diagonally measured, LCD panel/TFT active matrix system
(GR-DVL915)
3" diagonally measured, LCD panel/TFT active matrix system
(GR-DVL815)
2.5" diagonally measured, LCD panel/TFT active matrix system
(GR-DVL510/DVL310)
Viewfinder : Electronic viewfinder with 0.44" color LCD
(GR-DVL915/DVL815)
Electronic viewfinder with 0.24" black/white LCD
(GR-DVL510/DVL310)
Speaker : Monaural
For Digital Video Camera
Format : DV format (SD mode)
Signal format : NTSC standard
Recording/Playback format : Video: Digital component recording
: Audio: PCM digital recording, 32 kHz 4-channel (12-bit),
48 kHz 2-channel (16-bit)
Cassette : Mini DV cassette
Tape speed : SP: 18.8 mm/s
LP: 12.5 mm/s
Maximum recording time : SP: 80 min.
(using 80 min. cassette) LP: 120 min.
For Digital Still Camera (GR-DVL915/DVL815/DVL510 only)
Storage media : SD Memory Card/MultiMediaCard
Compression system : JPEG (compatible)
File size : VGA (640 x 480 pixels)
Picture quality : 2 modes (FINE/STANDARD)
Approximate number of storable images
with memory card [8 MB] (provided with GR-DVL510 only)
FINE : 100
STANDARD : 200
with memory card [16 MB] (provided with GR-DVL915/DVL815 only)
FINE : 200
STANDARD : 400
with memory card [32 MB] (optional)
FINE : 400
STANDARD : 800
with memory card [64 MB] (optional)
FINE : 800
STANDARD : 1600
For Connectors
S-Video
Output : Y : 1 V (p-p), 75 Ω, analog
C : 0.29 V (p-p), 75 Ω, analog
Input (GR-DVL915 only) : Y : 0.8 V (p-p) – 1.2 V (p-p), 75 Ω, analog
C : 0.2 V (p-p) – 0.4 V (p-p), 75 Ω, analog
AV
Video output : 1 V (p-p), 75 Ω, analog
Video input (GR-DVL915 only) : 0.8 V (p-p) – 1.2 V (p-p), 75 Ω, analog
Audio output : 300 mV (rms), 1 kΩ
, analog, stereo
Audio input (GR-DVL915 only) : 300 mV (rms), 50 kΩ, analog, stereo
DV
Output : 4-pin, IEEE 1394 compliant
Input : 4-pin, IEEE 1394 compliant
USB (GR-DVL915/DVL815/DVL510 only) : 5-pin
PC (DIGITAL PHOTO) (GR-DVL310 only) : ø2.5 mm, 3-pole
EDIT (GR-DVL915/DVL815/DVL510 only) : ø3.5 mm, 2-pole
JLIP (GR-DVL310 only) : ø3.5 mm, 4-pole
AC adapter AP-V10U
Power requirement
U.S.A. and Canada : AC 120 V `, 60 Hz
Other countries : AC 110 V to 240 V `, 50 Hz/60 Hz
Output : DC 11 V } , 1 A
Dimensions (W x H x D) : 59 mm x 31 mm x 84 mm (2-3/8" x 1-1/4" x 3-5/16")
Weight : Approx. 130 g (0.29 lbs.)
Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications
subject to change without notice.
