1-2 (No.MB161)
SPECIFICATION
Design and specifications are subject to change without notice.
Amplifier section-CA-HXGX7
Output Power
SUBWOOFERS 180 W per channel, min. RMS, driven into 6 Ω at 63 Hz with no more than 10 %total
harmonic distortion.
MAIN SPEAKERS 80 W per channel, min. RMS, driven into 6 Ω at 1 kHz with no more than 10 %total
harmonic distortion.
Audio input sensitivity/impedance (Measured at 1 kHz, with tape recording signal 300 mV)
AUX 300 mV/47 kΩ
Speakers/impedance SUBWOOFERS 6 Ω - 16 Ω
MAIN SPEAKERS 6 Ω - 16 Ω
Tuner
FM tuning range 87.5 MHz - 108.0 MHz
AM tuning range 530 kHz - 1 710 kHz
CD player
CD capacity 5 discs
Dynamic range 87 dB
Signal-to-noise ratio 90 dB
Wow and flutter Immeasurable
MP3 recording format MPEG 1/2 Audio Layer 3
Max. Bit rate 320 kbps
Cassette deck
Frequency response Normal (type I) 50 Hz - 14 000 Hz
Wow and flutter 0.15 % (WRMS)
General
Power requirement AC 120 V , 60 Hz
Power consumption 245 W/310 VA (at operation) 26 W (on standby)
Dimensions (approx.) 205 mm × 370 mm × 432 mm (W/H/D) (8 1/8 in. × 14 5/8 in. × 17 1/0 16 in.)
Mass (approx.) 10.5 kg (23.2 lbs)
Speaker section-SP-HXGX7
Type 3-Way 4-Speaker Bass-Reflex Type
Speaker Systems Subwoofer 16 cm (6 5/16 in.) cone × 1
Woofer 12 cm (4 3/4 in.) cone × 2
Tweeter 5 cm (2 in.) cone × 1
Power handling capacity Subwoofer 360 (180 + 180) W
Main speaker 160 (80 + 80) W
Impedance Subwoofer 6 Ω
Main speaker 6 Ω
Frequency range Subwoofer 27 Hz - 1000 Hz
Main speaker 70 Hz - 25 000 Hz
Sound pressure level Subwoofer 78 dB/W·m
Main speaker 88 dB/W·m
Dimensions (approx.) 227 mm × 432 mm × 376 mm (W/H/D) (8 15/16 in. × 17 1/16 in. × 14 13/16 in.)
Mass (approx.) 8 kg (17.7 lbs) each
