JVC HX-GX7 Service Manual

No. MB161 3-1
PARTS LIST
* All printed circuit boards and its assemblies are not available as service parts.
- Contents -
Exploded view of general assembly and parts list (Block No.M1)
Speaker assembly and parts list (Block No.M2)
CD changer mechanism assembly and parts list (Block No.MA)
CD mechanism assembly and parts list (Block No.MB)
Cassette mechanism assembly and parts list (Block No.MP)
Electrical parts list (Block No.01~07)
Packing materials and accessories parts list (Block No.M3)
[ HX-GX7 ]
3- 2
3- 5
3- 6
3- 8
3- 9
3-11
3-20
Area suffix
J ----------------------------- U.S.A.
C -------------------------- Canada

JVC HX-GX7 Specifications

General

Brand	JVC
Model	HX-GX7
Category	Speaker System
Language	English
