JVC HX-GX7 Service Manual

3-15
Front board
Block No. [0][3][0][0]
EP402 E409182-001SM GRAND TERMINAL
FW211 QUM154-40DGZ4 FLAT WIRE
FW401 QUM15A-12Z4Z4 FLAT WIRE
FW402 QUM153-12Z4Z4 FLAT WIRE
GND1 QUB220-13HPDT FLAT WIRE
GND2 QUB220-09HPDT SINGLE WIRE
J910 QNS0235-001 PHONE JACK
J1001 QNS0204-001 PHONE JACK
S900 QSW0825-001Z TACT SW
S901 QSW0825-001Z TACT SW
S902 QSW0825-001Z TACT SW
S903 QSW0825-001Z TACT SW
S904 QSW0825-001Z TACT SW
S905 QSW0825-001Z TACT SW
S906 QSW0825-001Z TACT SW
S907 QSW0825-001Z TACT SW
SP01 LV30225-011A SPACER
TW01 QUB230-10Z4Z4 FLAT WIRE
TW02 QUB230-10Z4Z4 FLAT WIRE
X801 QAX0724-001Z CRYSTAL 12.000000MHz
 Symbol No. Part No. Part Name Description Local
 IC600 STK432-070 IC
 IC660 KIA7805API IC
 IC670 KIA7805API IC
 IC700 STK412-430 POWER I.C
 IC750 KIA7808API IC
 IC760 KIA7809API IC
IC954 PT6305 FL DRIVER
IC955 SN74HCU04N FL DRIVER
Q600 KRC102M-T DIGI TRANSISTOR
Q601 KTA1267/YG/-T TRANSISTOR
Q602 KTC3199/GL/-T TRANSISTOR
Q603 KTC3199/GL/-T TRANSISTOR
Q604 2SK301/PQ/-T TRANSISTOR
Q700 KTC1027/OY/-T TRANSISTOR
Q701 KTA1023/OY/-T TRANSISTOR
Q702 KTC3200/GL/-T TRANSISTOR
Q703 KTA1268/GL/-T TRANSISTOR
Q704 KTC3199/GL/-T TRANSISTOR
Q705 KTC3199/GL/-T TRANSISTOR
Q706 KTA1267/YG/-T TRANSISTOR
Q904 KRC102M-T DIGI TRANSISTOR
Q905 KRC102M-T DIGI TRANSISTOR
Q906 KRC102M-T DIGI TRANSISTOR
Q907 KRC102M-T DIGI TRANSISTOR
Q908 KRC102M-T DIGI TRANSISTOR
Q950 KTC3199/GL/-T TRANSISTOR
Q951 KTC3199/GL/-T TRANSISTOR
Q952 KRA102M-T DIGI TRANSISTOR
D600 MTZJ9.1B-T2 Z DIODE
D601 1SS133-T2 DIODE
D602 1SS133-T2 DIODE
D603 MTZJ2.4B-T2 Z DIODE
D660 MTZJ8.2C-T2 Z DIODE
D661 1SS133-T2 DIODE
D670 1SS133-T2 DIODE
D671 MTZJ6.8C-T2 Z DIODE
D700 MTZJ36B-T2 Z DIODE
D701 MTZJ36B-T2 Z DIODE
D702 MTZJ15B-T2 Z DIODE
D703 MTZJ15B-T2 Z DIODE
D704 1SS133-T2 DIODE
D705 1SS133-T2 DIODE
D706 1SS133-T2 DIODE
D750 MTZJ10B-T2 Z DIODE
D760 MTZJ10B-T2 Z DIODE
D908 SLA-362LT-T LED
 Symbol No. Part No. Part Name Description Local
D909 SLA-362LT-T LED
D910 SLA-362LT-T LED
D911 SLA-362LT-T LED
D912 SLA-362LT-T LED
D913 SLR-342VC-T LED
C600 QTE1V06-106Z E CAPACITOR 10uF 35V
C601 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C602 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C603 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C604 QTE1V06-106Z E CAPACITOR 10uF 35V
C605 QETN1HM-107Z E CAPACITOR 100uF 50V M
C606 QETN1HM-106Z E CAPACITOR 10uF 50V M
C607 QETN1HM-106Z E CAPACITOR 10uF 50V M
C608 QETN1HM-107Z E CAPACITOR 100uF 50V M
C609 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C610 QCSB1HJ-100Y C CAPACITOR 10pF 50V J
C611 QETN1JM-476Z E CAPACITOR 47uF 63V M
C612 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C613 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C614 FQCF31HZ-223Z D.CAPACITOR
C615 QETN1JM-476Z E CAPACITOR 47uF 63V M
C616 QCSB1HJ-100Y C CAPACITOR 10pF 50V J
C617 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C618 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C619 FQCF31HZ-223Z D.CAPACITOR
C620 QFLC1HJ-823Z M CAPACITOR 0.082uF 50V J
C621 QETN1HM-224Z E CAPACITOR 0.22uF 50V M
C622 QETN1HM-105Z E CAPACITOR 1uF 50V M
C660 QETN1HM-106Z E CAPACITOR 10uF 50V M
C661 QETN1HM-106Z E CAPACITOR 10uF 50V M
C670 QETN1HM-106Z E CAPACITOR 10uF 50V M
C671 QETN1AM-227Z E CAPACITOR 220uF 10V M
C700 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C701 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C702 QTE1V06-106Z E CAPACITOR 10uF 35V
C703 QTE1V06-106Z E CAPACITOR 10uF 35V
C704 QCBB1HK-471Y C CAPACITOR 470pF 50V K
C705 QFZ0212-104Z M CAPACITOR 0.1uF
C706 QFZ0212-104Z M CAPACITOR 0.1uF
C707 QETN1CM-107Z E CAPACITOR 100uF 16V M
C708 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K
C709 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K
C710 FQCF31HZ-223Z D.CAPACITOR
C711 FQCF31HZ-223Z D.CAPACITOR
C712 QETN1JM-476Z E CAPACITOR 47uF 63V M
C713 QETN1JM-476Z E CAPACITOR 47uF 63V M
C714 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C715 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C716 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C717 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C718 QETN1HM-105Z E CAPACITOR 1uF 50V M
C719 QETN1HM-106Z E CAPACITOR 10uF 50V M
C750 QETN1HM-106Z E CAPACITOR 10uF 50V M
C751 QETN1CM-227Z E CAPACITOR 220uF 16V M
C760 QETN1HM-106Z E CAPACITOR 10uF 50V M
C761 QETN1HM-106Z E CAPACITOR 10uF 50V M
C931 QEKC1HM-226Z E CAPACITOR 22uF 50V M
C932 QEKC1HM-226Z E CAPACITOR 22uF 50V M
C935 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C936 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C937 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C938 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C939 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C940 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C941 QEKC0JM-107Z E CAPACITOR 100uF 6.3V M
C942 QEKC1HM-106Z E CAPACITOR 10uF 50V M
C943 QEKC1HM-106Z E CAPACITOR 10uF 50V M
R600 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R601 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R602 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R603 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
 R604 QRT01DJ-R22X MF RESISTOR 0.22 Ω 1W J
 R605 QRT01DJ-R22X MF RESISTOR 0.22 Ω 1W J
 R606 QRT01DJ-R22X MF RESISTOR 0.22 Ω 1W J
 R607 QRT01DJ-R22X MF RESISTOR 0.22 Ω 1W J
R608 QRE141J-333Y C RESISTOR 33k
Ω 1/4W J
 Symbol No. Part No. Part Name Description Local
