JVC HX-GX7 Service Manual

3-11
Electrical parts list
Power board
Block No. [0][1][0][0]
 Symbol No. Part No. Part Name Description Local
 IC201 KIA7812API IC
Q205 KTC3199/GL/-T TRANSISTOR
 Q206 KTC2026/OY/ TRANSISTOR
Q212 KTC3203/OY/-T TRANSISTOR
Q216 KTC3199/GL/-T TRANSISTOR
Q220 KTC3199/GL/-T TRANSISTOR
Q221 KTC3199/GL/-T TRANSISTOR
Q222 KTA1267/YG/-T TRANSISTOR
Q230 2SC3576-JVC-T TRANSISTOR
Q231 2SC3576-JVC-T TRANSISTOR
Q232 2SC3576-JVC-T TRANSISTOR
Q233 2SC3576-JVC-T TRANSISTOR
Q234 KRA111M-T DIGI TRANSISTOR
 D204 1N5402M-20 DIODE
 D205 1N5402M-20 DIODE
 D206 1N5402M-20 DIODE
 D207 1N5402M-20 DIODE
 D208 1N5402M-20 DIODE
 D209 1N5402M-20 DIODE
 D210 1N5402M-20 DIODE
 D211 1N5402M-20 DIODE
 D212 2A02-M DIODE
 D213 2A02-M DIODE
 D214 2A02-M DIODE
 D215 2A02-M DIODE
D221 MTZJ6.8B-T2 Z DIODE
D224 MTZJ18B-T2 Z DIODE
D225 MTZJ20B-T2 Z DIODE
D226 MTZJ5.1B-T2 Z DIODE
D227 1SS133-T2 DIODE
D228 1SS133-T2 DIODE
D229 1SS133-T2 DIODE
D230 1SS133-T2 DIODE
D231 1SS133-T2 DIODE
D237 MTZJ13B-T2 Z DIODE
D240 1SS133-T2 DIODE
D260 1SS133-T2 DIODE
D261 1SS133-T2 DIODE
C207 QFLC2AJ-103Z M CAPACITOR 0.01uF 100V J
C208 QFLC2AJ-103Z M CAPACITOR 0.01uF 100V J
C209 QETM1EM-688 E CAPACITOR 6800uF 25V M
C212 EETB1HM-228JC E CAPACITOR
C213 EETB1HM-228JC E CAPACITOR
C214 QFLC2AJ-103Z M CAPACITOR 0.01uF 100V J
C215 QFLC2AJ-103Z M CAPACITOR 0.01uF 100V J
C216 QFKC2EK-104Z MM CAPACITOR 0.1uF 250V K
C217 QEZ0613-478 E CAPACITOR 4700uF
C218 QEZ0613-478 E CAPACITOR 4700uF
C219 QFKC2EK-103Z MM CAPACITOR 0.01uF 250V K
C220 QCE22HP-103 C CAPACITOR 0.01uF 500V P
C221 QFKC2EK-103Z MM CAPACITOR 0.01uF 250V K
C225 QETN1HM-476Z E CAPACITOR 47uF 50V M
C227 QETN1HM-106Z E CAPACITOR 10uF 50V M
C228 QETN2AM-476Z E CAPACITOR 47uF 100V M
C229 QETN1HM-226Z E CAPACITOR 22uF 50V M
C230 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C231 QETN1HM-226Z E CAPACITOR 22uF 50V M
C232 QETN1EM-476Z E CAPACITOR 47uF 25V M
C237 QETN1HM-106Z E CAPACITOR 10uF 50V M
C238 QETN1HM-106Z E CAPACITOR 10uF 50V M
C240 QETN1HM-106Z E CAPACITOR 10uF 50V M
C241 QETN1EM-476Z E CAPACITOR 47uF 25V M
 R200 QRZ9037-335 COMP RESISTOR 3.3M Ω 1/2W K
 R204 QRK126J-470X UNF C RESISTOR 47 Ω 1/2W J
 R205 QRK126J-470X UNF C RESISTOR 47 Ω 1/2W J
R206 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R207 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R208 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R209 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R211 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
 R212 QRJ146J-470X UNF C RESISTOR 47 Ω 1/4W J
R213 QRE141J-752Y C RESISTOR 7.5k
Ω 1/4W J
R214 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
 R225 QRJ146J-6R8X UNF C RESISTOR 6.8 Ω 1/4W J
R226 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R227 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R228 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R229 QRE141J-153Y C RESISTOR 15k Ω 1/4W J
R230 QRE141J-153Y C RESISTOR 15k Ω 1/4W J
R231 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R232 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R234 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R236 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R237 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R238 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R239 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R240 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R241 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R242 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R243 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R250 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R251 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R252 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R253 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
 R254 QRL01DJ-471X OMF RESISTOR 470 Ω 1W J
 R255 QRL01DJ-471X OMF RESISTOR 470 Ω 1W J
 R260 QRK126J-331X UNF C RESISTOR 330 Ω 1/2W J
 R261 QRK126J-331X UNF C RESISTOR 330 Ω 1/2W J
 R262 QRK126J-331X UNF C RESISTOR 330 Ω 1/2W J
 R263 QRK126J-331X UNF C RESISTOR 330 Ω 1/2W J
 R264 QRK126J-331X UNF C RESISTOR 330 Ω 1/2W J
 R265 QRK126J-331X UNF C RESISTOR 330 Ω 1/2W J
 R275 QRZ9006-4R7X F.RESISTOR 4.7 Ω 1/4W J
 R277 QRZ9006-4R7X F.RESISTOR 4.7 Ω 1/4W J
L250 QQL231K-470Y COIL 47uH K
CN200 QGA7901C1-02 CONNECTOR W-B (1-2)
CN201 QGD2504C1-04Z CONNECTOR (1-4)
CN202 QGA2501C1-03 CONNECTOR W-B (1-3)
CN205 QGD2504C1-03Z CONNECTOR (1-3)
CN206 QGA2501C1-10 CONNECTOR W-B (1-10)
CN207 QGB2510K1-13 CONNECTOR B-B (1-13)
CN208 QGA2501C1-11 CONNECTOR W-B (1-11)
CN213 QGD2504C1-04Z CONNECTOR (1-4)
CN214 QGA3901C1-08 CONNECTOR W-B (1-8)
EP200 QNZ0136-001Z EARTH PLATE
EP201 QNZ0136-001Z EARTH PLATE
FT200 QNG0003-001Z FUSE CLIP
FT201 QNG0003-001Z FUSE CLIP
FT220 QNG0003-001Z FUSE CLIP
FT221 QNG0003-001Z FUSE CLIP
FT230 QNG0003-001Z FUSE CLIP
FT231 QNG0003-001Z FUSE CLIP
FT250 QNG0003-001Z FUSE CLIP
FT251 QNG0003-001Z FUSE CLIP
FW202 QUM154-20DGZ4 FLAT WIRE
FW204 QJK015-082614 FLAT WIRE
J200 QNB0193-002 SPK.TERMINAL
PP200 QZW0038-001 WIRE CLAMP
RY1 QSK0109-001 RELAY
RY2 QSK0109-001 RELAY
