JVC KD-X161 Quick Start Guide

6
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
RADIO
Search for a station
1 Press SRC-B repeatedly to select FM or AM.
2 Press S / T to search for a station automatically.
(or)
Press and hold S / T until “M” flashes, then press repeatedly to
search for a station manually.
Settings in memory
You can store up to 18 stations for FM and 6 stations for AM.
Store a station
While listening to a station....
Press and hold one of the number buttons (1 to 6).
(or)
1 Press and hold * ENTER until “PRESETMODE” flashes.
2 Press VOL +/– to select a preset number, then press * ENTER.
“MEMORY” appears once the station is stored.
Select a stored station
Press one of the number buttons (1to6).
(or)
1 Press .
2 Press VOL +/– to select a preset number, then press * ENTER.
USB/ANDROID
Start playback
The source changes automatically and playback starts when you attach a
device (USB device/ Android device) to the USB input terminal.
To On the faceplate
Reverse/Fast-forward
Press and hold S / T.
Select a file
Press S / T.
Select a folder
Press 2 J / 1 K.
Repeat play
Press 4  repeatedly.
Random play
Press 3  repeatedly.
JS_JVC_QSG_KD_X161_E_EN_int1.indd 6JS_JVC_QSG_KD_X161_E_EN_int1.indd 6 6/14/2018 4:33:12 PM6/14/2018 4:33:12 PM

JVC KD-X161 Specifications

General

DIN size	1 DIN
Impedance	4 Ω
Output power	200 W
Product color	Black
Ready for iPod	-
Volume control	Rotary
Low pass filter	Yes
Disc types supported	No
Audio output channels	- channels
Maximum power per channel	50 W
Package width	900 mm
USB version	2.0
USB port position	Front
USB connector type	USB Type-A
USB ports quantity	1
Headphone connectivity	3.5mm
Display type	LCD
Number of OSD languages	3
On Screen Display (OSD) languages	ENG, FRE, RUS

Weight and Dimensions

Depth	53 mm
Width	182 mm
Height	100 mm
Weight	600 g
