2-12
KS-F150
KS-FX12
Description of major ICs
UPC1228HA (IC901) : Head Amplifier HA13158 (IC981) : BTL Amplifier
ANP1
ANP2
UPC1228HA
1
2
3
4
5
6
7
8
IN1
NFB1
OUT1
VCC
GND
OUT2
NFB2
IN2
