JVC LT-19D200 Service Manual

(No.YA711<Rev.001>)3-9
JACK P.W. BOARD ASS'Y (FU-1ESA20948-1)
R805 FU-RRXAJR5Z08R2 MG RESISTOR 8.2 Ω 1/10W J
R808 FU-RRXAJR5Z0472 MG RESISTOR 4.7k
Ω 1/10W J
R809 FU-RRXAJR5Z0361 MG RESISTOR 360
Ω 1/10W J
R810 FU-RRXAJR5Z0562 MG RESISTOR 5.6k
Ω 1/10W J
R811 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω 1/10W J
R813 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω 1/10W J
R814 FU-RRXAJR5Z0562 MG RESISTOR 5.6k
Ω 1/10W J
R815 FU-RRXAJR5Z0471 MG RESISTOR 470
Ω 1/10W J
R816 FU-RRXAJR5Z0471 MG RESISTOR 470
Ω 1/10W J
R817 FU-RRXAJR5Z0183 MG RESISTOR 18k
Ω 1/10W J
R818 FU-RRXAJR5Z0153 MG RESISTOR 15k
Ω 1/10W J
R819 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω 1/10W J
R820 FU-RRXAJR5Z0472 MG RESISTOR 4.7k
Ω 1/10W J
R821 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R823 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R826 FU-RCX4103T1001 C RESISTOR 10K
Ω 1/4W J
R830 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω 1/10W J
R834 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω 1/10W J
R836 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R837 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R838 FU-RCX4103T1001 C RESISTOR 10K
Ω 1/4W J
R842 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R904 FU-RCX4103T1001 C RESISTOR 10K
Ω 1/4W J
R905 FU-RCX4103T1001 C RESISTOR 10K
Ω 1/4W J
R906 FU-RCX4561T1001 C RESISTOR 560
Ω 1/4W J
R907 FU-RRXAJR5Z0222 MG RESISTOR 2.2k
Ω 1/10W J
R908 FU-RRXAJR5Z0222 MG RESISTOR 2.2k
Ω 1/10W J
R909 FU-RRXAJR5Z0101 MG RESISTOR 100
Ω 1/10W J
R910 FU-RRXAR30HH007 MG RESISTOR 0.30
Ω 1/10W J
R911 FU-RRXAR30HH007 MG RESISTOR 0.30
Ω 1/10W J
R912 FU-RCX4102T1001 C RESISTOR 1.0k
Ω 1/4W J
R913 FU-RCX23R9T1003 C RESISTOR 3.9
Ω 1/2W J
R914 FU-RCX23R9T1003 C RESISTOR 3.9
Ω 1/2W J
R915 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω 1/10W J
R916 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω 1/10W J
R917 FU-RCX4391T1001 C RESISTOR 390
Ω 1/4W J
R918 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω 1/10W J
R919 FU-RCX4151T1001 C RESISTOR 150
Ω 1/4W J
R920 FU-RRXAFR5H3301 MG RESISTOR 3.3k
Ω 1/10W F
R921 FU-RRXAFR5H1002 MG RESISTOR 10k
Ω 1/10W F
R922 FU-RCX4220T1001 C RESISTOR 22
Ω 1/4W J
R923 FU-RCX4221T1001 C RESISTOR 220
Ω 1/4W J
R924 FU-RCX45R6T1001 C RESISTOR 5.6
Ω 1/4W J
R925 FU-RCX45R6T1001 C RESISTOR 5.6
Ω 1/4W J
R926 FU-RCX4471T1001 C RESISTOR 470
Ω 1/4W J
R927 FU-RCX4100T1001 C RESISTOR 10
Ω 1/4W J
R928 FU-RCX4181T1001 C RESISTOR 180
Ω 1/4W J
R929 FU-RCX41R2T1001 C RESISTOR 1.2
Ω 1/4W J
R930 FU-RN026R8ZU001 O.M.F.RESISTOR 6.8
Ω 2W J
R931 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R933 FU-RCX4104T1001 C RESISTOR 100k
Ω 1/4W J
R935 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω 1/10W J
R936 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω 1/10W J
R940 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω 1/10W J
R941 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R942 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R943 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω 1/10W J
L13 FU-GBJB3080 SCREW
L301 FU-LLBF00STU030 INDUCTOR
L302 FU-LLACKB3TUR22 INDUCTOR
L303 FU-LLACKB3TUR22 INDUCTOR
 L601 FU-LLBG00ZKT004 LINE FILTER
 T1002 FU-LTZ3PZ0XB014 INVERTER TRANS
 T601 FU-LTT2PC0XB044 POWER TRANS
 AC601 FU-WAC0172LW008 POWER CORD
B12 FU-1EM423968 HEAT SINK
B13 FU-1EM324377 HEAT SINK
B14 FU-1EM423993 HEAT SINK
BC301 FU-LLC601NTU017 INDUCTOR
BC601 FU-LLBF00STU030 INDUCTOR
BC801 FU-LLC601NTU017 INDUCTOR
BC901 FU-LLC601NTU017 INDUCTOR
BC902 FU-RRXAZR5Z0000 MG RESISTOR 0
Ω 1/10W
 CN1001 FU-JB17D02AP001 CONNECTOR
 CN1002 FU-JB17D02AP001 CONNECTOR
CN102 FU-J322C08TG001 CONNECTOR
CN201 FU-JC96J11ER007 FFC CONNECTOR
CN301 FU-JC96J29ER007 FFC CONNECTOR
CN302 FU-JC96J29ER007 FFC CONNECTOR
CN303 FU-JC96J29ER007 FFC CONNECTOR
CN702 FU-JC96J29ER007 FFC CONNECTOR
CN862A FU-J322C04TG001 CONNECTOR
CN901 FU-JC96J26ER007 FFC CONNECTOR
CN902 FU-JC62G13UG026 CONNECTOR
 F601 FU-PAGE20CW3402 FUSE 125V 4A
FH601 FU-XH01Z00LY002 FUSE HOLDER
FH602 FU-XH01Z00LY002 FUSE HOLDER
 Ref No. Part No. Part Name Description Local
JS304 FU-RRXAZR5Z0000 MG RESISTOR 0 Ω 1/10W
JS801 FU-RRXAZR5Z0000 MG RESISTOR 0
Ω 1/10W
JS802 FU-RRXAZR5Z0000 MG RESISTOR 0
Ω 1/10W
JS803 FU-RRXAZR5Z0000 MG RESISTOR 0
Ω 1/10W
JS804 FU-RRXAZR5Z0000 MG RESISTOR 0
Ω 1/10W
 SA601 FU-NVQZ10D471KB SURGE ABSORBER
TM601 FU-0VM406868 EYELET
TM602 FU-0VM406868 EYELET
TU302 FU-UTUNNTUAL052 TUNER UNIT
 Ref No. Part No. Part Name Description Local
IC771 FU-QSZBA0TTS162 IC SWITCHING
Q722 FU-NQS4KTC3199P TRANSISTOR
Q771 FU-NQS4KTC3199P TRANSISTOR
Q773 FU-NQS4KTC3199P TRANSISTOR
Q774 FU-NQS4KTC3199P TRANSISTOR
Q841 FU-NQS4KTC3199P TRANSISTOR
C703 FU-CHD1CZ30F105 C CAPACITOR 1uF 16V
C704 FU-CHD1CZ30F105 C CAPACITOR 1uF 16V
C723 FU-CHD1CZ30F105 C CAPACITOR 1uF 16V
C724 FU-CHD1CZ30F105 C CAPACITOR 1uF 16V
C731 FU-CHD1JJ3CH390 C CAPACITOR 39pF 50V J
C732 FU-CHD1JJ3CH390 C CAPACITOR 39pF 50V J
C733 FU-CHD1JJ3CH390 C CAPACITOR 39pF 50V J
C734 FU-RRXAZR5Z0000 MG RESISTOR 0
Ω 1/10W
C735 FU-RRXAZR5Z0000 MG RESISTOR 0
Ω 1/10W
C736 FU-RRXAZR5Z0000 MG RESISTOR 0
Ω 1/10W
C743 FU-CHD1CZ30F105 C CAPACITOR 1uF 16V
C744 FU-CHD1CZ30F105 C CAPACITOR 1uF 16V
C751 FU-CHD1JJ3CH101 C CAPACITOR 100pF 50V J
C752 FU-CHD1JJ3CH101 C CAPACITOR 100pF 50V J
C753 FU-CHD1JJ3CH101 C CAPACITOR 100pF 50V J
C754 FU-RRXAZR5Z0000 MG RESISTOR 0
Ω 1/10W
C755 FU-RRXAZR5Z0000 MG RESISTOR 0
Ω 1/10W
C756 FU-RRXAZR5Z0000 MG RESISTOR 0
Ω 1/10W
C757 FU-CHD1CZ30F105 C CAPACITOR 1uF 16V
C758 FU-CHD1CZ30F105 C CAPACITOR 1uF 16V
C771 FU-CE1CMAVSL101 E CAPACITOR 100uF 16V
C772 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V
C773 FU-CHD1CZ30F105 C CAPACITOR 1uF 16V
C775 FU-CHD1JJ3CH330 C CAPACITOR 33pF 50V
C776 FU-CHD1JJ3CH330 C CAPACITOR 33pF 50V
C841 FU-CHD1CZ30F105 C CAPACITOR 1uF 16V
C842 FU-CHD1CZ30F105 C CAPACITOR 1uF 16V
C843 FU-CHD1JZ30F104 C CAPACITOR 0.1uF 50V
C845 FU-CHD1JJ3CH330 C CAPACITOR 33pF 50V
R711 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R712 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R717 FU-RRXAJR5Z0563 MG RESISTOR 56k
Ω 1/10W J
R718 FU-RRXAJR5Z0563 MG RESISTOR 56k
Ω 1/10W J
R721 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R722 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R727 FU-RRXAJR5Z0563 MG RESISTOR 56k
Ω 1/10W J
R728 FU-RRXAJR5Z0563 MG RESISTOR 56k
Ω 1/10W J
R731 FU-RRXAFR5H75R0 MG RESISTOR 75
Ω 1/10W F
R732 FU-RRXAFR5H75R0 MG RESISTOR 75
Ω 1/10W F
R733 FU-RRXAFR5H75R0 MG RESISTOR 75
Ω 1/10W F
R734 FU-RRXAJR5Z0100 MG RESISTOR 10
Ω 1/10W J
R735 FU-RRXAJR5Z0100 MG RESISTOR 10
Ω 1/10W J
R736 FU-RRXAJR5Z0100 MG RESISTOR 10
Ω 1/10W J
R741 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R742 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R747 FU-RRXAJR5Z0563 MG RESISTOR 56k
Ω 1/10W J
R748 FU-RRXAJR5Z0563 MG RESISTOR 56k
Ω 1/10W J
R751 FU-RRXAJR5Z0750 MG RESISTOR 75
Ω 1/10W J
R752 FU-RRXAJR5Z0750 MG RESISTOR 75
Ω 1/10W J
R753 FU-RRXAJR5Z0750 MG RESISTOR 75
Ω 1/10W J
R754 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R755 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R756 FU-RCX4100T1001 C RESISTOR 10
Ω 1/4W J
R757 FU-RCX4100T1001 C RESISTOR 10
Ω 1/4W J
R758 FU-RCX4100T1001 C RESISTOR 10
Ω 1/4W J
R763 FU-RCX4563T1001 C RESISTOR 56K
Ω 1/4W J
R764 FU-RRXAJR5Z0563 MG RESISTOR 56k
Ω 1/10W J
R772 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω 1/10W J
R773 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω 1/10W J
R774 FU-RCX4103T1001 C RESISTOR 10K
Ω 1/4W J
R775 FU-RCX4103T1001 C RESISTOR 10K
Ω 1/4W J
R780 FU-RRXAJR5Z0823 MG RESISTOR 82k
Ω 1/10W J
 Ref No. Part No. Part Name Description Local
