JVC LT-19D200 Service Manual

3-10(No.YA711<Rev.001>)
FUNCTION P.W. BOARD ASS'Y (FU-1ESA20948-2)
JUNCTION-A P.W. BOARD ASS'Y (FU-1ESA20948-3)
JUNCTION-B P.W. BOARD ASS'Y (FU-1ESA20948-4)
JUNCTION-C P.W. BOARD ASS'Y (FU-1ESA20948-5)
R781 FU-RRXAJR5Z0823 MG RESISTOR 82k Ω 1/10W J
R782 FU-RCX4823T1001 C RESISTOR 82k
Ω 1/4W J
R783 FU-RRXAJR5Z0823 MG RESISTOR 82k
Ω 1/10W J
R784 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R785 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R786 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R787 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R788 FU-RCX4823T1001 C RESISTOR 82k
Ω 1/4W J
R789 FU-RCX4823T1001 C RESISTOR 82k
Ω 1/4W J
R790 FU-RRXAJR5Z0823 MG RESISTOR 82k
Ω 1/10W J
R791 FU-RRXAJR5Z0823 MG RESISTOR 82k
Ω 1/10W J
R792 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R793 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R794 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R795 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R796 FU-RRXAJR5Z0222 MG RESISTOR 2.2k
Ω 1/10W J
R797 FU-RRXAJR5Z0222 MG RESISTOR 2.2k
Ω 1/10W J
R843 FU-RRXAJR5Z0111 MG RESISTOR 110
Ω 1/10W J
R844 FU-RRXAJR5Z0221 MG RESISTOR 220
Ω 1/10W J
R845 FU-RRXAJR5Z0104 MG RESISTOR 100k
Ω 1/10W J
R846 FU-RRXAJR5Z0101 MG RESISTOR 100
Ω 1/10W J
R847 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω 1/10W J
R848 FU-RRXAJR5Z0103 MG RESISTOR 10k
Ω 1/10W J
R851 FU-RCX4181T1001 C RESISTOR 180
Ω 1/4W J
R852 FU-RCX4181T1001 C RESISTOR 180
Ω 1/4W J
BC771 FU-LLBF00STU030 INDUCTOR
BC841 FU-LLC601NTU017 INDUCTOR
CN701 FU-JC96J29ER007 FFC CONNECTOR
CN861A FU-J322C04TG001 CONNECTOR
JK711 FU-JXSJ020YUQ01 MINI JACK PC-AUDIO-IN
JK721 FU-JXRJ010YUQ02 PIN JACK HDMI-AUDIO(L)-IN
JK722 FU-JXRJ010YUQ01 PIN JACK HDMI-AUDIO(R)-IN
JK731 FU-JXRJ010YUQ03 PIN JACK COMPONENT-Y-IN
JK732 FU-JXRJ010YUQ04 PIN JACK COMPONENT-Pb-IN
JK733 FU-JXRJ010YUQ01 PIN JACK COMPONENT-Pr-IN
JK741 FU-JXRJ010YUQ02 PIN JACK
COMPONENT-AUDIO(L)-IN
JK742 FU-JXRJ010YUQ01 PIN JACK COMPONENT-AUDIO(R)-IN
JK751 FU-JYEL040YUQ03 JACK S-VIDEO-IN
JK752 FU-JXRL010YUQ12 JACK VIDEO-IN
JK753 FU-JXRL010YUQ13 JACK AUDIO(L)-IN
JK754 FU-JYRL010YUQ05 JACK AUDIO(R)-IN
JK841 FU-JXRJ010YUQ06 RCA JACK DIGITAL AUDIO OUT
JK851 FU-JYSL010YUQ03 JACK HEADPHONE
JS701 FU-RRXAZR5Z0000 MG RESISTOR 0
Ω 1/10W
 Ref No. Part No. Part Name Description Local
D103 FU-NP4Z000L53HT LED STAND BY
D104 FU-NPQ3L1CHCBK2 LED POWER
D950 FU-NPWZ0LTL307Y LED DVD
C103 FU-CE1CMAVSL470 E CAPACITOR 47uF 16V M
C104 FU-CHD1JK30B331 C CAPACITOR 330pF 50V
C107 FU-CHD1CZ30F105 C CAPACITOR 1uF 16V
C108 FU-CA1J104TU062 C CAPACITOR 0.1uF 50V
C109 FU-CA1J104TU062 C CAPACITOR 0.1uF 50V
C951 FU-CA1J104TU062 C CAPACITOR 0.1uF 50V
R106 FU-RCX4101T1001 C RESISTOR 100
Ω 1/4W J
R107 FU-RRXAJR5Z0332 MG RESISTOR 3.3k
Ω 1/10W J
R108 FU-RRXAJR5Z0221 MG RESISTOR 220
Ω 1/10W J
R109 FU-RRXAJR5Z0152 MG RESISTOR 1k
Ω 1/10W J
R110 FU-RRXAJR5Z0102 MG RESISTOR 1k
Ω 1/10W J
R111 FU-RRXAFR5H1802 MG RESISTOR 18k
Ω 1/10W F
R112 FU-RRXAFR5H8201 MG RESISTOR 8.2k
Ω 1/10W F
R113 FU-RRXAFR5H0472 MG RESISTOR 4.7k
Ω 1/10W F
R114 FU-RRXAFR5H2701 MG RESISTOR 2.7k
Ω 1/10W F
R115 FU-RRXAFR5H0472 MG RESISTOR 4.7k
Ω 1/10W F
R116 FU-RCX4221T1001 C RESISTOR 220
Ω 1/4W J
R118 FU-RRXAFR5H1002 MG RESISTOR 10k
Ω 1/10W F
R950 FU-RCX4221T1001 C RESISTOR 220
Ω 1/4W J
R952 FU-RRXAFR5H2201 MG RESISTOR 2.2k
Ω 1/10W F
R953 FU-RRXAFR5H2201 MG RESISTOR 2.2k
Ω 1/10W F
R956 FU-RRXAFR5H1002 MG RESISTOR 10k
Ω 1/10W F
RS101 FU-USESJRSKK046 REMOTE SENSOR
SW104 FU-SST0101AL049 TACT SWITCH VOL-
SW105 FU-SST0101AL049 TACT SWITCH VOL+
SW106 FU-SST0101AL049 TACT SWITCH MENU
SW107 FU-SST0101AL049 TACT SWITCH CH-
SW108 FU-SST0101AL049 TACT SWITCH CH+
SW109 FU-SST0101AL049 TACT SWITCH POWER
 Ref No. Part No. Part Name Description Local
SW951 FU-SST0101AL049 TACT SWITCH PLAY
SW952 FU-SST0101AL049 TACT SWITCH STOP
SW953 FU-SST0101AL049 TACT SWITCH EJECT
 Ref No. Part No. Part Name Description Local
CL101 FU-WX1A94N0-001 WIRE ASSY
CN101 FU-JCTUB08TG002 CONNECTOR
 Ref No. Part No. Part Name Description Local
CL862 FU-WX1A94N0-002 WIRE ASSY
CN862B FU-JCTUB04TG002 CONNECTOR
 Ref No. Part No. Part Name Description Local
CL861 FU-WX1A94N0-002 WIRE ASSY
CN861B FU-JCTUB04TG002 CONNECTOR
 Ref No. Part No. Part Name Description Local
