32
PC connection
Follow these steps: On your PC monitor choose a resolution of 1360 × 768 at 60Hz and save this
configuration. Shut down your PC and connect the shut off LCD TV.
Use a screensaver to avoid burning-in of static picture content.
Use a PC-VGA cable (not supplied) to connect the LCD-Monitor
to your PC. Make the connections carefully so as not to break or
bend the contacts inside the plug.
Select PC input
Switch on the LCD-TV.
Select the PC input mode (see page 12).
Note:
If no signal or a signal with a non-
supported resolution is connected, No
Signal is displayed
As this LCD-TV is not a PC monitor
correct display cannot be guaranteed for
every PC / graphics card.
•
•
Selected Items
Setup hint
Setup
PC Setup
Auto Adjust H Position, V Position, Phase and Clock are adjusted
automatically as per the input PC video signal.
When PC-input mode was selected and a PC-signal was
input, Auto Adjust will be performed automatically.
•
H Position To adjust the horizontal placing of the image.
V Position To adjust the vertical placing of the image.
Phase Eliminates the horizontal (PHASE) interfering lines.
Clock Eliminates the vertical (CLOCK) interfering lines.
Example: Adjust the H Position.
1
During PC mode press MENU.
Auto Adjust
H Position
V Position
Phase
Clock
Sound
Channel
Feature
Setup
0
0
0
0
Setup - PC Setup
2
Select Setup/PC Setup/H Position, then press ENTER.
Press
or to adjust H Position.
3
Press RETURN several times to return to the normal
screen.
Supported PC resolutions
resolution fps (Hz)
640x480 60
800x600 60
1024x768 60
1280x720 60
1280x768 60
1360x768 60
1280x1024 60
1440x900 60
1920x1080 60
VGA Cable (not supplied)
Audio cable (not supplied)
TV (Rear view)
to PC/DVI AUDIO input
PC
55L0501A_ENG.indd 3255L0501A_ENG.indd 32 11/25/10 11:32:32 AM11/25/10 11:32:32 AM
