1-2 (No.MB011)
SPECIFICATION
Amplifier section
Output Power SUB WOOFERS 88 W per channel, min. RMS, both channels driven into 6 Ω at 63
Hz with no more than 0.9% total harmonic distortion.
MAIN SPEAKERS 28 W per channel, min. RMS, both channels driven into 6 Ω at 1
kHz with no more than 0.9% total harmonic distortion.
Audio input sensitivity/Impedance
(Measured at 1 kHz, with tape
recording signal 300 mV)
AUX 390 mV/50 kΩ
MIC 1/2 3.0 mV/5 kΩ
Digital output CD OPTICAL DIGITAL OUTPUT
Signal wave length 660 nm
Output level -15 dBm to -12 dBm
Speakers/Impedance SUB WOOFERS 6 Ω - 16 Ω
MAIN SPEAKERS 6 Ω - 16 Ω
SURROUND SPEAKERS 16 Ω - 32 Ω
Tuner
FM tuning range 87.50 MHz - 108.00 MHz
AM tuning range For Saudi Arabia At 9 kHz intervals : 531 kHz - 1 602 kHz
At 10 kHz intervals : 530 kHz - 1 600 kHz
For other countries At 9 kHz intervals : 531 kHz - 1 710 kHz
At 10 kHz intervals : 530 kHz - 1 710 kHz
CD player
CD capacity 3 CDs
Dynamic range 85 dB
Signal-to-noise ratio 90 dB
Wow and flutter Immeasurable
Cassette deck
Frequency response Normal (type I) 50 Hz - 14 000 Hz
Wow and flutter 0.15% (WRMS)
General
Power requirement AC 110 V / AC 127 V / AC 220 V / AC 230 V - AC 240 V~(adjustable with the voltage selector),
50 Hz / 60 Hz
Power consumption 170 W (at operation) 25 W (on standby)
Dimensions (approx.) 265 mm × 335 mm × 401 mm (W/H/D) (10 7/16 in. × 13 1/4 in. × 15 13/16 in.)
Mass (approx.) 10.0 kg (22.1 lbs)
