JVC MX-GA9V User Manual

3-15
Electrical parts list
Power board
Block No. [0][1][0][0]
 Symbol No. Part No. Part Name Description Local
 IC602 STK402-050 IC(HYBRID) 2ch AF power amp.
 IC701 STK412-010 POWER I.C
Q201 2SB740/BC/-T TRANSISTOR
Q240 2SC2785/FE/-T TRANSISTOR
Q372 KTA1023/OY/-T TRANSISTOR
Q373 KRA104M-T DIGI TRANSISTOR
Q374 KRC104M-T TRANSISTOR
Q601 KTA1268/GL/-T TRANSISTOR
Q602 KTA1268/GL/-T TRANSISTOR
Q612 2SA1175/FE/-T TRANSISTOR
Q613 KRC102M-T DIGI TRANSISTOR
Q680 2SK301/PQ/-T TRANSISTOR
Q701 KTA1268/GL/-T TRANSISTOR
Q702 KTA1268/GL/-T TRANSISTOR
Q710 2SA965/OY/-T TRANSISTOR
Q711 KTC3200/GL/-T TRANSISTOR
Q712 KTA1268/GL/-T TRANSISTOR
Q713 KTC1027/OY/-T TRANSISTOR
Q726 2SC2389S/SE/-T TRANSISTOR
Q727 KTA1268/GL/-T TRANSISTOR
Q728 2SC2785/FE/-T TRANSISTOR
Q733 2SC3576-JVC-T TRANSISTOR
Q734 2SC3576-JVC-T TRANSISTOR
Q735 2SC3576-JVC-T TRANSISTOR
Q736 2SC3576-JVC-T TRANSISTOR
Q737 KRA111M-T DIGI TRANSISTOR
Q790 2SC2785/FE/-T TRANSISTOR
Q791 2SC2785/FE/-T TRANSISTOR
Q792 KTC3203/OY/-T TRANSISTOR
 D201 1N5402M-20 DIODE
 D202 1N5402M-20 DIODE
 D203 1N5402M-20 DIODE
 D204 1N5402M-20 DIODE
 D211 1N5402M-20 DIODE
 D212 1N5402M-20 DIODE
 D213 1N5402M-20 DIODE
 D214 1N5402M-20 DIODE
 D217 1N4003S-T5 SI DIODE
 D218 1N4003S-T5 SI DIODE
D219 DZ33BSC-T2 Z DIODE
D220 DZ9.1BSB-T2 Z DIODE
 D227 1N4003S-T5 SI DIODE
 D233 2A02-M DIODE
 D234 2A02-M DIODE
D280 DZ2.4BSB-T2 Z DIODE
D369 DZ10BSC-T2 Z DIODE
D370 DZ11BSC-T2 Z DIODE
D619 1SS119-041-T2 DIODE
D620 1SS119-041-T2 DIODE
D622 DZ9.1BSB-T2 Z DIODE
D703 DZ15BSC-T2 Z DIODE
D704 DZ15BSC-T2 Z DIODE
D719 1SS119-041-T2 DIODE
D720 1SS119-041-T2 DIODE
D723 DZ36BSA-T2 Z DIODE
D724 DZ36BSA-T2 Z DIODE
D726 1SS119-041-T2 DIODE
D728 1SS119-041-T2 DIODE
D790 1SS119-041-T2 DIODE
C201 QFKC2EK-104 MM CAPACITOR 0.1uF 250V K
C202 QFKC2EK-104 MM CAPACITOR 0.1uF 250V K
C203 QFKC2EK-104 MM CAPACITOR 0.1uF 250V K
C204 EETB1JM-478JC E CAPACITOR
C205 EETB1JM-478JC E CAPACITOR
C211 QFLC1HJ-823Z M CAPACITOR 0.082uF 50V J
C212 QFLC1HJ-823Z M CAPACITOR 0.082uF 50V J
C213 QFLC1HJ-823Z M CAPACITOR 0.082uF 50V J
C214 EETB1HM-228JC E CAPACITOR
C215 EETB1HM-228JC E CAPACITOR
C216 QETN1VM-107Z E CAPACITOR 100uF 35V M
C217 EETC2AM-476ZJC E CAPACITOR
C218 EETC1HM-226ZJC E CAPACITOR
C219 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C220 EETC1HM-476ZJC E CAPACITOR
C221 EETC1HM-476ZJC E CAPACITOR
C222 EETC1HM-476ZJC E CAPACITOR
C253 EETB1EM-688JC E CAPACITOR
C280 EETC1HM-224ZJC E CAPACITOR
C281 QETN1JM-476Z E CAPACITOR 47uF 63V M
C372 EETC1HM-226ZJC E CAPACITOR
C373 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C374 EETC1HM-226ZJC E CAPACITOR
C601 QFVJ1HJ-683Z MF CAPACITOR 0.068uF 50V J
C602 QFVJ1HJ-683Z MF CAPACITOR 0.068uF 50V J
C603 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C604 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C605 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C606 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C607 QETN1JM-476Z E CAPACITOR 47uF 63V M
C608 QETN1JM-476Z E CAPACITOR 47uF 63V M
C609 QCSB1HJ-100Y C CAPACITOR 10pF 50V J
C610 QCSB1HJ-100Y C CAPACITOR 10pF 50V J
C611 QETN1HM-476Z E CAPACITOR 47uF 50V M
C612 QETN1HM-476Z E CAPACITOR 47uF 50V M
C613 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C614 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C615 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C616 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C621 QTE1V06-106Z E CAPACITOR 10uF 35V
C622 QTE1V06-106Z E CAPACITOR 10uF 35V
C623 QETN1HM-106Z E CAPACITOR 10uF 50V M
C624 QETN1HM-106Z E CAPACITOR 10uF 50V M
C639 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C683 QFLC1HJ-823Z M CAPACITOR 0.082uF 50V J
C703 QCBB1HK-471Y C CAPACITOR 470pF 50V K
C704 QCBB1HK-471Y C CAPACITOR 470pF 50V K
C705 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C706 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C707 QETN1JM-476Z E CAPACITOR 47uF 63V M
C708 QETN1JM-476Z E CAPACITOR 47uF 63V M
C709 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K
C710 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K
C711 QFZ0212-104Z M CAPACITOR 0.1uF
C712 QFZ0212-104Z M CAPACITOR 0.1uF
C713 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C714 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C715 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C716 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C721 QTE1V06-106Z E CAPACITOR 10uF 35V
C722 QTE1V06-106Z E CAPACITOR 10uF 35V
C723 EETC1AM-107ZJC E CAPACITOR
C726 EETC1EM-106ZJC E CAPACITOR
C729 EETC1CM-476ZJC E CAPACITOR
C730 QCF31HZ-223Z C CAPACITOR 0.022uF 50V Z
C731 QCF31HZ-223Z C CAPACITOR 0.022uF 50V Z
C739 EETC1HM-105ZJC E CAPACITOR
C790 EETC1EM-476ZJC E CAPACITOR
C901 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C902 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
 R202 QRZ9042-2R2X F RESISTOR 2.2 Ω
R203 QRE141J-752Y C RESISTOR 7.5k Ω 1/4W J
R204 QRE141J-223Y C RESISTOR 22k
Ω 1/4W J
R205 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R215 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R216 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R217 QRE141J-273Y C RESISTOR 27k
Ω 1/4W J
R218 QRE141J-273Y C RESISTOR 27k
Ω 1/4W J
 R220 QRJ146J-470X UNF C RESISTOR 47 Ω 1/4W J
R242 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
 R246 QRJ146J-1R0X UNF C RESISTOR 1 Ω 1/4W J
 R247 QRJ146J-1R0X UNF C RESISTOR 1 Ω 1/4W J
 R248 QRJ146J-1R0X UNF C RESISTOR 1 Ω 1/4W J
 Symbol No. Part No. Part Name Description Local
