JVC RX-7040B Service Manual

RX-7040B
3-5
Electrical parts list
Main board
Block No. [0][1][0][0]
Front board
Block No. [0][2][0][0]
 Symbol No. Part No. Part Name Description Local
Q811 2SD2394/EF/ TRANSISTOR
Q812 KTC3200/GL/-T TRANSISTOR
Q823 KTC3199/GL/-T TRANSISTOR
Q824 KTC3200/GL/-T TRANSISTOR
Q825 KTA1268/GL/-T TRANSISTOR
Q830 KRC109M-T DIGI TRANSISTOR
Q831 KRC109M-T DIGI TRANSISTOR
Q832 KRC109M-T DIGI TRANSISTOR
Q833 KRC109M-T DIGI TRANSISTOR
Q834 KRC109M-T DIGI TRANSISTOR
Q835 KRC109M-T DIGI TRANSISTOR
Q836 KRC109M-T DIGI TRANSISTOR
Q837 KRC109M-T DIGI TRANSISTOR
Q838 KRC109M-T DIGI TRANSISTOR
Q839 KRC109M-T DIGI TRANSISTOR
 D801 30PRA20-FC SI DIODE
 D802 30PRA20-FC SI DIODE
 D803 30PRA20-FC SI DIODE
 D804 30PRA20-FC SI DIODE
D811 MTZJ24C-T2 Z DIODE
D816 MTZJ18C-T2 Z DIODE
D825 1SS133-T2 DIODE
D831 1SS133-T2 DIODE
D832 1SS133-T2 DIODE
D841 MTZJ5.1C-T2 Z DIODE
D842 1SS133-T2 DIODE
D843 1SS133-T2 DIODE
D844 1SS133-T2 DIODE
D845 1SS133-T2 DIODE
D846 1SS133-T2 DIODE
D847 1SS133-T2 DIODE
D848 1SS133-T2 DIODE
D851 1SS133-T2 DIODE
D852 1SS133-T2 DIODE
D853 1SS133-T2 DIODE
D871 1SS133-T2 DIODE
C454 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C801 QCE22HP-103 C CAPACITOR 0.01uF 500V P
C802 QCE22HP-103 C CAPACITOR 0.01uF 500V P
C805 QCE22HP-103 C CAPACITOR 0.01uF 500V P
C807 QEZ0679-688 E CAPACITOR 6800uF
C808 QEZ0679-688 E CAPACITOR 6800uF
C811 QCF31HZ-472Z C CAPACITOR 4700pF 50V Z
C816 QETN1EM-107Z E CAPACITOR 100uF 25V M
C823 QETN1CM-476Z E CAPACITOR 47uF 16V M
C824 QETN1EM-106Z E CAPACITOR 10uF 25V M
C850 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C851 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C852 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C853 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
R91 QRL027J-471 OMF RESISTOR 470 Ω 2W J
R92 QRL027J-471 OMF RESISTOR 470
Ω 2W J
R801 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R802 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R811 QRJ146J-150X UNF C RESISTOR 15
Ω 1/4W J
R812 QRK126J-332X UNF C RESISTOR 3.3k
Ω 1/2W J
R813 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R814 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R815 QRJ146J-120X UNF C RESISTOR 12
Ω 1/4W J
R816 QRL027J-332 OMF RESISTOR 3.3k
Ω 2W J
R823 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R824 QRE141J-134Y C RESISTOR 130k Ω 1/4W J
R825 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R826 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R831 QRZ9005-330X FUSI RESISTOR 33 Ω
R832 QRZ9005-330X FUSI RESISTOR 33 Ω
R841 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R842 QRE141J-823Y C RESISTOR 82k Ω 1/4W J
R843 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R844 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R845 QRE141J-823Y C RESISTOR 82k Ω 1/4W J
R846 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R851 QRZ9005-330X FUSI RESISTOR 33
Ω
R852 QRZ9005-330X FUSI RESISTOR 33 Ω
R854 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R855 QRJ146J-392X UNF C RESISTOR 3.9k Ω 1/4W J
R856 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R857 QRE141J-682Y C RESISTOR 6.8k Ω 1/4W J
R858 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R859 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R860 QRE141J-682Y C RESISTOR 6.8k Ω 1/4W J
R861 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R862 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R863 QRE141J-682Y C RESISTOR 6.8k Ω 1/4W J
R864 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R865 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R866 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R867 QRE141J-223Y C RESISTOR 22k
Ω 1/4W J
R868 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R869 QRE141J-682Y C RESISTOR 6.8k Ω 1/4W J
R870 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R871 QRZ9005-330X FUSI RESISTOR 33 Ω
R886 QRZ9005-330X FUSI RESISTOR 33 Ω
CN701 QGB2510J1-12 CONNECTOR B-B (1-12)
CN702 QGB2510J1-12 CONNECTOR B-B (1-12)
CN703 QGB2510J1-10 CONNECTOR B-B (1-10)
CN704 QGB2510J1-10 CONNECTOR B-B (1-10)
CN705 QGB2510J1-12 CONNECTOR B-B (1-12)
CN706 QGB2510J1-12 CONNECTOR B-B (1-12)
CN723 QGA2501C1-04 CONNECTOR W-B (1-4)
CN801 QJK012-032403 SKT WIRE ASSY
CN813 QGA3901C1-06 CONNECTOR W-B (1-6)
CN814 QGA3901C1-07 CONNECTOR W-B (1-7)
CN823 QJK015-063001 C-B WIRE ASSY
CN824 QJK015-073202 SKT WIRE ASSY
CN831 QGD2501C1-04Z CONNECTOR (1-4)
CN881 QGD2501C1-03Z CONNECTOR (1-3)
EP91 E406523-001SM GND BKT
EP801 QNZ0136-001Z EARTH PLATE
FW881 QUM213-40DGZ4 PARA RIBON WIRE
FW931 QUM218-08DGZ4 PARA RIBON WIRE
J91 QNS0022-001 JACK
RY831 QSK0109-001 RELAY
RY832 QSK0109-001 RELAY
RY851 QSK0109-001 RELAY
RY852 QSK0109-001 RELAY
RY853 QSK0109-001 RELAY
RY871 QSK0109-001 RELAY
ST832 QNB0082-002 SPK TERMINAL
ST833 QNB0078-001 SPK TERMINAL
ST853 QNB0105-002 SPK.TERMINAL
 Symbol No. Part No. Part Name Description Local
PW402 QUB131-18DMPP CONNECTOR
IC201 MM1117XF-XE IC
IC202 NJM2246M-X IC
IC241 MM1113XF-X IC
IC242 MM1114XF-X IC
IC243 MM1117XF-XE IC
IC244 NJM2246M-X IC
IC303 NJM4565M-WE IC
IC371 TC9163AF-X IC
IC400 MN101C35DMF IC
 Symbol No. Part No. Part Name Description Local
