JVC RX-7040B Service Manual

RX-7040B
3-13
DSP board
Block No. [0][6][0][0]
R1446 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1447 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R1471 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1472 NRSA63J-511X MG RESISTOR 510 Ω 1/16W J
R1473 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R1474 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1475 NRSA63J-512X MG RESISTOR 5.1k
Ω 1/16W J
R1476 NRSA63J-113X MG RESISTOR 11k Ω 1/16W J
R1478 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1486 NRSA63J-511X MG RESISTOR 510 Ω 1/16W J
R1487 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1490 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1505 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
CN205 QGB1214J1-10S CONNECTOR B-B (1-10)
CN381 QGB1214J1-18S CONNECTOR B-B (1-18)
CN501 QGB1214J1-14S CONNECTOR B-B (1-14)
CN731 QJP002-021901 SHI CR C-B WIRE
CN732 QJP001-031701 SHI CR C-B WIRE
CN733 QJP017-021701 SHI CR C-B WIRE
CN734 WJP0047-001A E-SH C WIRE C-B
CN735 QJP007-031301 CONNECTOR
J1350 QNS0089-001 3.5 JACK
J1352 QNS0089-001 3.5 JACK
J1360 QNN0548-001 4PIN JACK ASSY
J1380 QNN0391-001 PIN JACK
J1491 QNN0284-001 PIN JACK
 Symbol No. Part No. Part Name Description Local
IC601 NJM4565M-WE IC
IC602 NJM4565M-WE IC
IC611 NJM4565M-WE IC
IC612 NJM4565M-WE IC
IC613 NJM4565M-WE IC
IC614 NJM4565M-WE IC
IC621 NJM4565M-WE IC
IC622 NJM4565M-WE IC
IC631 NJM2120M-X IC
IC632 NJM4565M-WE IC
IC633 NJM4565M-WE IC
IC634 NJM4565M-WE IC
IC651 NJM4565M-WE IC
IC661 DSPA56370AF IC
IC662 SN74LVC1GU04K-X IC
IC667 CS42518-CQZ-C-X IC(DIGITAL)
IC671 UPD784217AGC257 IC(FLASH MICOM)
IC672 SN74AHCT1G32K-X IC
IC673 SN74LVC1G04K-X IC
IC681 JCV8009-W IC
IC682 MN35505-X IC
IC683 SN74AHC2G74T-X IC
IC684 SN74LVC2G241T-X IC
IC691 BA3259HFP-W IC
Q2101 2SD2114K/VW/-X TRANSISTOR
Q2102 2SD2114K/VW/-X TRANSISTOR
Q2141 2SD601A/RS/-X TRANSISTOR
Q2142 2SD601A/RS/-X TRANSISTOR
Q2201 2SD2114K/VW/-X TRANSISTOR
Q2202 2SD2114K/VW/-X TRANSISTOR
Q2221 2SD2114K/VW/-X TRANSISTOR
Q2222 2SD2114K/VW/-X TRANSISTOR
Q2301 2SD2114K/VW/-X TRANSISTOR
Q2341 2SD601A/RS/-X TRANSISTOR
Q2401 2SD2114K/VW/-X TRANSISTOR
Q2421 2SD2114K/VW/-X TRANSISTOR
Q2501 2SD2114K/VW/-X TRANSISTOR
Q2701 UN2214-X TRANSISTOR
Q2702 UN2214-X TRANSISTOR
Q2703 UN2214-X TRANSISTOR
 Symbol No. Part No. Part Name Description Local
Q2704 UN2114-X TRANSISTOR
Q2705 UN2114-X TRANSISTOR
Q2706 UN2114-X TRANSISTOR
Q2708 UN2114-X TRANSISTOR
Q2709 UN2114-X TRANSISTOR
Q2710 UN2214-X TRANSISTOR
C2001 QETN1EM-475Z E CAPACITOR 4.7uF 25V M
C2002 QETN1EM-475Z E CAPACITOR 4.7uF 25V M
C2005 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2006 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2009 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2010 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2013 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2014 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2018 QETN1AM-476Z E CAPACITOR 47uF 10V M
C2019 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2020 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2101 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2102 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2109 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2110 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2111 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2112 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2113 NCB31HK-331X C CAPACITOR 330pF 50V K
C2114 NCB31HK-331X C CAPACITOR 330pF 50V K
C2115 NCB31HK-272X C CAPACITOR 2700pF 50V K
C2116 NCB31HK-272X C CAPACITOR 2700pF 50V K
C2129 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2131 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2132 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2133 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2134 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2139 QETN1EM-475Z E CAPACITOR 4.7uF 25V M
C2140 QETN1EM-475Z E CAPACITOR 4.7uF 25V M
C2141 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2142 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2143 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2144 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2149 QETN1EM-475Z E CAPACITOR 4.7uF 25V M
C2150 QETN1EM-475Z E CAPACITOR 4.7uF 25V M
C2161 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2162 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2163 NDC31HJ-181X C CAPACITOR 180pF 50V J
C2164 NDC31HJ-181X C CAPACITOR 180pF 50V J
C2165 NCB31CK-683X C CAPACITOR 0.068uF 16V K
C2166 NCB31CK-683X C CAPACITOR 0.068uF 16V K
C2167 NCB31HK-182X C CAPACITOR 1800pF 50V K
C2168 NCB31HK-182X C CAPACITOR 1800pF 50V K
C2201 NCB31HK-182X C CAPACITOR 1800pF 50V K
C2202 NCB31HK-182X C CAPACITOR 1800pF 50V K
C2209 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C2210 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C2229 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2230 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2241 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2242 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2243 NCB31HK-562X C CAPACITOR 5600pF 50V K
C2244 NCB31HK-562X C CAPACITOR 5600pF 50V K
C2245 NCB31HK-182X C CAPACITOR 1800pF 50V K
C2246 NCB31HK-182X C CAPACITOR 1800pF 50V K
C2249 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C2250 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C2281 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2282 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2283 NCB31HK-471X C CAPACITOR 470pF 50V K
C2284 NCB31HK-471X C CAPACITOR 470pF 50V K
C2285 NCB31HK-471X C CAPACITOR 470pF 50V K
C2286 NCB31HK-471X C CAPACITOR 470pF 50V K
C2287 NCB31HK-682X C CAPACITOR 6800pF 50V K
C2288 NCB31HK-682X C CAPACITOR 6800pF 50V K
C2301 NCB31HK-272X C CAPACITOR 2700pF 50V K
C2309 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C2323 NCB31HK-562X C CAPACITOR 5600pF 50V K
C2325 NCB31HK-182X C CAPACITOR 1800pF 50V K
C2341 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2342 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2343 NDC31HJ-330X C CAPACITOR 33pF 50V J
 Symbol No. Part No. Part Name Description Local
