JVC RX-7040B Service Manual

RX-7040B
3-7
Micon board
Block No. [0][3][0][0]
R396 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R397 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R398 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R400 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R401 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R402 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R403 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R404 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R405 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R406 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R407 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R408 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R409 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R410 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R411 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R412 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R413 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R414 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R415 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R416 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R417 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R418 NRSA63J-152X MG RESISTOR 1.5k
Ω 1/16W J
R422 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R423 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R424 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R425 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R426 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R427 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R428 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R429 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R430 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R431 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R432 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R433 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R434 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R435 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R441 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R442 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R445 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R446 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R447 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R448 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R449 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R450 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R451 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R453 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R454 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R455 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R456 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R457 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R459 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R460 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R461 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R462 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R463 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R464 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R465 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R466 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R468 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R480 NRSA63J-152X MG RESISTOR 1.5k
Ω 1/16W J
R481 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R482 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R483 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R484 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R485 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
BK400 LV42092-001A FL HOLDER(R)
BK401 LV42093-001A FL HOLDER(L)
CN200 QGB2510K1-12 CONNECTOR B-B (1-12)
CN204 QGB1214K1-10S CONNECTOR B-B (1-10)
CN240 QGB2510K1-09 CONNECTOR B-B (1-9)
CN313 QGB2510K1-17 CONNECTOR B-B (1-17)
CN314 QGF1205F1-11 CONNECTOR FFC/FPC (1-11)
CN315 QGB2510K1-04 CONNECTOR B-B (1-4)
CN371 QGB1214K1-18S CONNECTOR B-B (1-18)
CN410 QGF1205F1-09 CONNECTOR FFC/FPC (1-9)
CN412 QGF1205F1-06 CONNECTOR FFC/FPC (1-6)
CN420 QJK031-031301 C-B WIRE ASSY
 Symbol No. Part No. Part Name Description Local
CN422 QJK031-041201 SIN ID C-B WIRE
CN430 QGA2501C1-03 CONNECTOR W-B (1-3)
CN432 QGA2501C1-04 CONNECTOR W-B (1-4)
DI400 QLF0137-001 FL TUBE
FL351 QQR1372-001 LPF
FL352 QQR1372-001 LPF
FS400 LV30225-0S7A SPACER
FS401 LV30225-0S7A SPACER
J201 QNN0011-001 PIN JACK
J202 QNN0011-001 PIN JACK
J204 QNN0017-002 PIN JACK
J241 QND0108-001 S-CONNECTOR
J242 QND0098-001 DIN CONNECTOR
J244 QND0107-001 S JACK
J371 QNN0018-002 PIN JACK
J372 QNN0018-002 PIN JACK
J373 QNN0546-001 PIN JACK
JS400 QSW1017-001 JOG VOLUME
JS401 QSW1015-001 ROTARY ENCODER
S400 QSW0683-001Z PUSH SW
S401 QSW0683-001Z PUSH SW
S402 QSW0683-001Z PUSH SW
S403 QSW0683-001Z PUSH SW
S404 QSW0683-001Z PUSH SW
S405 QSW0683-001Z PUSH SW
S406 QSW0683-001Z PUSH SW
S407 QSW0683-001Z PUSH SW
S408 QSW0683-001Z PUSH SW
S409 QSW0683-001Z PUSH SW
S411 QSW0683-001Z PUSH SW
S412 QSW0683-001Z PUSH SW
S414 QSW0683-001Z PUSH SW
S415 QSW0683-001Z PUSH SW
S416 QSW0683-001Z PUSH SW
S417 QSW0683-001Z PUSH SW
S418 QSW0683-001Z PUSH SW
S422 QSW0683-001Z PUSH SW
S424 QSW0683-001Z PUSH SW
S425 QSW0683-001Z PUSH SW
S427 QSW0683-001Z PUSH SW
S428 QSW0683-001Z PUSH SW
S429 QSW0683-001Z PUSH SW
S430 QSW0683-001Z PUSH SW
S432 QSW0683-001Z PUSH SW
S433 QSW0683-001Z PUSH SW
S434 QSW0683-001Z PUSH SW
S480 QSW0683-001Z PUSH SW
S481 QSW0683-001Z PUSH SW
S482 QSW0683-001Z PUSH SW
S483 QSW0683-001Z PUSH SW
X400 QAX0246-001Z C RESONATOR 8.00MHz
 Symbol No. Part No. Part Name Description Local
PW12 QUB111-16PPPP WIRE
PW16 QUB116-16PPPP PIN WIRE
PW18 QUB112-28PPPP SIN TWIST WIRE
PW19 QUB111-28PPPP SIN TWIST WIRE
PW30 QUB116-28PPPP SIN TWIST WIRE
IC901 MN101C49GMX IC
IC903 IC-PST9139-T IC
IC990 BR24L01AF-W-X IC
Q52 KTD863/Y/-T TRANSISTOR
Q53 KRC105M-T DIGI TRANSISTOR
Q71 KTA1046/Y/ TRANSISTOR
Q74 KTC3200/GL/-T TRANSISTOR
Q901 KRC107M-T DIGI TRANSISTOR
Q903 KRC105M-T DIGI TRANSISTOR
Q904 KRC105M-T DIGI TRANSISTOR
 Symbol No. Part No. Part Name Description Local
