JVC RX-7040B Service Manual

RX-7040B
3-9
Power board
Block No. [0][4][0][0]
R992 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R993 NRSA63J-622X MG RESISTOR 6.2k Ω 1/16W J
R994 NRSA63J-512X MG RESISTOR 5.1k Ω 1/16W J
R995 NRSA63J-133X MG RESISTOR 13k Ω 1/16W J
R996 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R997 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R998 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
 T2 QQT0434-001 POWER TRANSF
CN55 QGD2501C1-05Z CONNECTOR (1-5)
CN71 QGB2510J1-09 CONNECTOR B-B (1-9)
CN72 QGB2510K1-09 CONNECTOR B-B (1-9)
CN81 QGB2510J1-08 CONNECTOR B-B (1-8)
CN82 QGB2510K1-08 CONNECTOR B-B (1-8)
CN101 QGB2510J1-04 CONNECTOR B-B (1-4)
CN201 QGB2510J1-12 CONNECTOR B-B (1-12)
CN241 QGB2510J1-09 CONNECTOR B-B (1-9)
CN303 QGB2510J1-17 CONNECTOR B-B (1-17)
CN400 QGF1205C1-09 CONNECTOR FFC/FPC (1-9)
CN402 QGF1205C1-06 CONNECTOR FFC/FPC (1-6)
CN601 QGB2510J1-07 CONNECTOR B-B (1-7)
CN811 QGA3901F2-03 CONNECTOR W-B (1-3)
CN931 QGD2501C1-04Z CONNECTOR (1-4)
CN932 QGD2501C1-04Z CONNECTOR (1-4)
EP1 E409182-001SM GRAND TERMINAL
EP51 QNZ0136-001Z EARTH PLATE
EP901 QNZ0136-001Z EARTH PLATE
EP902 QNZ0136-001Z EARTH PLATE
FC1 QNG0020-001Z FUSE CLIP
FC2 QNG0020-001Z FUSE CLIP
FC61 QNG0020-001Z FUSE CLIP
FC62 QNG0020-001Z FUSE CLIP
FC63 QNG0020-001Z FUSE CLIP
FC64 QNG0020-001Z FUSE CLIP
FW51 QUM215-10DGZ4 PARA RIBON WIRE
FW831 QUM214-08DGZ4 PARA RIBON WIRE
HS921 E70945-H40B HEAT SINK
HS961 E70306-001 HEAT SINK
HS971 E70306-001 HEAT SINK
 RY1 QSK0098-001 RELAY
TA1 QNZ0079-001Z TAB
TA2 QNZ0079-001Z TAB
 TH71 QAD0095-4R7Z P THERMISTOR 4.7 Ω M
X901 QAX0246-001Z C RESONATOR 8.00MHz
 Symbol No. Part No. Part Name Description Local
Q701 2SC2240-BL/AB/T TRANSISTOR
Q702 2SC2240-BL/AB/T TRANSISTOR
Q703 2SC2240-BL/AB/T TRANSISTOR
Q704 2SC2240-BL/AB/T TRANSISTOR
Q705 KTA1268/GL/-T TRANSISTOR
Q706 KTA1268/GL/-T TRANSISTOR
Q707 KTA1268/GL/-T TRANSISTOR
Q708 KTA1268/GL/-T TRANSISTOR
Q709 KTA1268/GL/-T TRANSISTOR
Q710 KTA1268/GL/-T TRANSISTOR
Q711 KTC3200/GL/-T TRANSISTOR
Q712 KTC3200/GL/-T TRANSISTOR
 Q761 2SD2390/PY/-F6 TRANSISTOR
 Q762 2SD2390/PY/-F6 TRANSISTOR
 Q763 2SB1560/PY/-F6 TRANSISTOR
 Q764 2SB1560/PY/-F6 TRANSISTOR
Q771 KTC3200/GL/-T TRANSISTOR
Q772 KTC3200/GL/-T TRANSISTOR
Q773 KTA1268/GL/-T TRANSISTOR
Q774 KTA1268/GL/-T TRANSISTOR
Q781 2SD637/QR/ TRANSISTOR
Q782 2SD637/QR/ TRANSISTOR
Q791 KTA1268/GL/-T TRANSISTOR
 Symbol No. Part No. Part Name Description Local
Q792 KTA1268/GL/-T TRANSISTOR
Q1701 2SC2240-BL/AB/T TRANSISTOR
Q1702 2SC2240-BL/AB/T TRANSISTOR
Q1703 KTA1268/GL/-T TRANSISTOR
Q1731 2SD637/QR/ TRANSISTOR
 Q1751 2SD2390/PY/-F6 TRANSISTOR
 Q1752 2SB1560/PY/-F6 TRANSISTOR
Q1771 KTC3200/GL/-T TRANSISTOR
Q1772 KTA1268/GL/-T TRANSISTOR
Q1791 KTA1268/GL/-T TRANSISTOR
Q1801 2SC2240-BL/AB/T TRANSISTOR
Q1802 2SC2240-BL/AB/T TRANSISTOR
Q1803 2SC2240-BL/AB/T TRANSISTOR
Q1804 2SC2240-BL/AB/T TRANSISTOR
Q1805 KTA1268/GL/-T TRANSISTOR
Q1806 KTA1268/GL/-T TRANSISTOR
Q1831 2SD637/QR/ TRANSISTOR
Q1832 2SD637/QR/ TRANSISTOR
 Q1851 2SD2390/PY/-F6 TRANSISTOR
 Q1852 2SD2390/PY/-F6 TRANSISTOR
 Q1853 2SB1560/PY/-F6 TRANSISTOR
 Q1854 2SB1560/PY/-F6 TRANSISTOR
Q1871 KTC3200/GL/-T TRANSISTOR
Q1872 KTC3200/GL/-T TRANSISTOR
Q1873 KTA1268/GL/-T TRANSISTOR
Q1874 KTA1268/GL/-T TRANSISTOR
Q1891 KTA1268/GL/-T TRANSISTOR
Q1892 KTA1268/GL/-T TRANSISTOR
Q1901 2SC2240-BL/AB/T TRANSISTOR
Q1902 2SC2240-BL/AB/T TRANSISTOR
Q1903 KTA1268/GL/-T TRANSISTOR
Q1931 2SD637/QR/ TRANSISTOR
 Q1951 2SD2390/PY/-F6 TRANSISTOR
 Q1952 2SB1560/PY/-F6 TRANSISTOR
Q1971 KTC3200/GL/-T TRANSISTOR
Q1972 KTA1268/GL/-T TRANSISTOR
Q1991 KTA1268/GL/-T TRANSISTOR
D701 1SS133-T2 DIODE
D702 1SS133-T2 DIODE
D703 1SS133-T2 DIODE
D704 1SS133-T2 DIODE
D771 1SS133-T2 DIODE
D772 1SS133-T2 DIODE
D773 1SS133-T2 DIODE
D774 1SS133-T2 DIODE
D791 1SS133-T2 DIODE
D792 1SS133-T2 DIODE
D1701 1SS133-T2 DIODE
D1771 1SS133-T2 DIODE
D1772 1SS133-T2 DIODE
D1791 1SS133-T2 DIODE
D1801 1SS133-T2 DIODE
D1802 1SS133-T2 DIODE
D1871 1SS133-T2 DIODE
D1872 1SS133-T2 DIODE
D1873 1SS133-T2 DIODE
D1874 1SS133-T2 DIODE
D1891 1SS133-T2 DIODE
D1892 1SS133-T2 DIODE
D1901 1SS133-T2 DIODE
D1971 1SS133-T2 DIODE
D1992 1SS133-T2 DIODE
D1993 1SS133-T2 DIODE
C701 QTE1V06-106Z E CAPACITOR 10uF 35V
C702 QTE1V06-106Z E CAPACITOR 10uF 35V
C703 QCS31HJ-101Z C CAPACITOR 100pF 50V J
C704 QCS31HJ-101Z C CAPACITOR 100pF 50V J
C705 QCS31HJ-101Z C CAPACITOR 100pF 50V J
C706 QCS31HJ-101Z C CAPACITOR 100pF 50V J
C707 QETN1CM-107Z E CAPACITOR 100uF 16V M
C708 QETN1CM-107Z E CAPACITOR 100uF 16V M
C709 QCS31HJ-100Z C CAPACITOR 10pF 50V J
C710 QCS31HJ-100Z C CAPACITOR 10pF 50V J
C711 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C712 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C713 QCS31HJ-680Z C CAPACITOR 68pF 50V J
 Symbol No. Part No. Part Name Description Local
